Harley Motorcycle Footboard Assembly

Remove the two screws in the footboard assembly.

Slide the footboard assembly from the motorcycle.

Replacement Instructions

Model Numbers: 74290, 74370

Remove Screws

White Connector

Turn the footboard assembly on its side. Gently wiggle to remove

the white connector from the black terminal.

Discard Footboard Assembly

Discard the footboard assembly.

Black Terminal

Need help?

Do you have a question about the POWER WHEELS 74290 and is the answer not in the manual?

Page 1 Harley Motorcycle Footboard Assembly Replacement Instructions Model Numbers: 74290, 74370 White Connector White Connector Black Terminal Black Terminal Remove Screws Remove Screws Remove the two screws in the footboard assembly. Turn the footboard assembly on its side. Gently wiggle to remove the white connector from the black terminal.
Page 2 East Aurora, New York 14052. Hearing-impaired consumers using TTY/TDD equipment, please call 1-800-382-7470. Printed in USA Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. ©2008 Mattel, Inc. All Right Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. 74290pr-0922...
