6 www.electrolux.com
3.

USE

3.1 The Control Panel

PROGRAM SELECTOR KNOB
1
Turn the Program Selector knob to
choose a drying program.
The table "Program Guide"
shown on page 7 will help
you in selecting the right program.
NOTES : The Program Selector knob
is not a timer. Once you select a
drying program, the Program Selector
knob will stay at that position for
the whole drying cycle.
3 START/PAUSE BUTTON
This button allows you to start or
pause the dryer to check the
contents or perhaps add more
clothes.
NOTES : The dryer will not start
unless the door is closed.
(If door is not closed you
will hear 6 beeps followed by
DRY LED blinking 4 times.)
If selector knob is turned while
dryer is running or paused
mid cycle 3 beeps is heard to
indicate operation is not allowed.
Cycle will not continue if selector
knob is not returned to original
selected program.
1
INDICATORS
2
STATES
Initial Power on.
• After appliance is powered on.
Allows user to select a drying
•
program
Machine Switched Off
Drying Phase
• Drying cycle starts.
• Buzzer will sound after main
drying and cooling phases
ends, at the start of
anticrease.
• Anticrease in progress
Paused
• Drying cycle paused
• Cannot change drying program
End State
• Drying cycle and
Anticrease completed
Alarm/ Error
See description on page 10
•
2 3
STATUS INDICATOR
• Dry LED blinks
• End LED Off
• All LED Off
Drying & Cooling
• Dry LED On
• End LED Off
Anticrease
• Dry LED Off
• End LED blinks
• Dry LED blinks
End LED Off
• Dry LED Off
• End LED Off
• Dry LED blinks
• End LED blinks
