MLSC C-80 Operator's Manual

C-80
DMX LIGHTING CONTROLLER
C-80
channels
1 3
2
______________
4 5
7 8
9
0
scene Program
Chase
Operators Manual
MLSC Inc. MLSC Inc. MLSC Inc. MLSC Inc.
8000 Madison Pike, Madison, Alabama 35758
Tel (256) 461–8000
Website: meteor-global.com
1/8
DMX LIGHTING CONTROLLER
1 2 3 4 5 7
0 1 2 3 4 5 6 7 8
Active Fixtures / Page Selection
Program
Enter
Scene
Fax: (256) 461–7708
e-mail: sales@meteor-usa.com
C C C C - - - - 80 DMX CONTROLLER 80 DMX CONTROLLER
80 DMX CONTROLLER 80 DMX CONTROLLER
Please read these instructions carefully before attempting to
operate / program controller. Once you feel you understand the
instructions, locate the instructions in a place where you will
remember where they are for future reference and additional help in
using your controller
CONTENTS:
1 -
2 -
3 -
8 4 -
INTRODUCTION / FEATURES
1.
The C-80 DMX CONTROLLER is a standard DMX 512
Controller capable of controlling up to 80 DMX channels
simultaneously. Simplicity to operate and use, and had to
9
maintain high quality programmability was the mission
statement.
The main features include:
10 Fixtures up to 8 channels each
100 Scenes capable
35 Chases – each up to 48 Scenes
8 Faders to adjust DMX output level from 0 – 255.
Extremely Easy Operation and Programming
Mix and Match any DMX Lighting fixture
Power On / Off switch on back of Controller
SPECIFICATIONS:
2
Power Input: DC9 – 12v 300mA
DMX OUTPUT: 3 Pin or 5 pin Female XLR connector
Size: 12" L x 6.5" w x 2.5" h (not rack mountable)
Weight: 7lbs
Power supply: included
2/8
INTRODUCTION / FEATURES
FUNCTIONS
OPERATING INSTRUCTIONS
TROUBLE SHOOTING
