IPTV125 Quick Setup

1. Login Setup Page:

Press "Help" button on the remote controller when TV shows 'Starting" screen. Input "1234" as
password with number keys, move focus to "OK" by clicking cursor "R" key and then click "OK"
to enter normal setting.
2. After finishing IPv4/IPv6 setting, you'll find the portal page URL as below:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPTV125 and is the answer not in the manual?

Questions and answers

Summary of Contents for AllWell IPTV125

  • Page 1 IPTV125 Quick Setup 1. Login Setup Page: Press “Help” button on the remote controller when TV shows 'Starting" screen. Input “1234” as password with number keys, move focus to “OK” by clicking cursor ”R” key and then click “OK” to enter normal setting.
  • Page 2 The portal page means the homepage that STB links after booting or press “HOME” key at remote. It can set to “Kumat”, “Himi” or “User”. If “User”, please input address format as below in the input text field. The address format of “Portal Page” and “Upgrade Page” can be http(s) web page or html file inside STB.
  • Page 3 ["4","NSC","mcast://172.15.5.7/vbs1multi.nsc"], //IPv4 Windows Media multicast ["5","H264","rtsp://172.22.123.112/unit111"], //IPv4 RTSP H.264 ["101","KCC2","httptv://10.10.10.1/stream/Bikini_California.1440x1080.ts"], //IPv4 HTTP file ["102","CCITV","httptv://[fec0::1]/stream/test.mpg"], //IPv6 HTTP file ["103","Feeling","httptv://streamer.ipstb.orion/stream/test.tp"], //FQDN HTTP file ["201","News77","tv://"+xsystem.ip4Addr+":1234"]]; //IPv4 UDP unicast Above is a default channel map, please insert channels format into list as above. Be aware the red color syntax at the head and the end. Himi Interface: himi.xml The IPTV channel setting is inside <ChannelLiat>…</ChannelLiat>...
