- Page 1 INSTRUCTION MANUAL TT-SI 7002 25MHz active differential probe x20 / x50 /x200...
-
Page 3: Safety Summary
In environments where there is a danger of any liquid on the probe. spilled • In air temperatures exceeding the specified operating temperatures. • In atmospheric pressures outside the specified altitude limits or where the surrounding gas is not air. Man_7002_0919 www.testec.de... -
Page 4: Terms And Symbols
Terms and Symbols The following symbols appear on the product or in its documentation: Direct voltage Both direct and alternating voltage Caution, possibility of electric shock Caution, see documentation for details Earth Ground Man_7002_0919 www.testec.de... -
Page 5: Compliance Statements
August 13, 2005, and should not be disposed of as unsorted municipal waste. Please utilize your local WEEE collection facilities in the disposition of this product and otherwise observe all applicable requirements. This probe is in compliance with IEC 61010-031:2015 CAT III, Pollution Degree 2. Man_7002_0919 www.testec.de... -
Page 6: Using The Probe
1 Introduction Overview The TT-SI 7002 differential probe allows safe, accurate measurement between two voltage points where neither point is referenced to ground. The probe offers both a 25 MHz bandwidth for the x50x and x200 attenuation settings and 15 MHz bandwidth for the x20 attenuation setting. - Page 7 0,5 V/div 10 V/div 1 MΩ 0,5 V/div 25 V/div 1 MΩ x200 x200 0,5 V/div 100 V/div 50 Ω 0,5 V/div 20 V/div 50 Ω x100 0,5 V/div 50 V/div 50 Ω x200 x400 0,5 V/div 200 V/div Man_7002_0919 www.testec.de...
-
Page 8: Product Overview
3 Product Overview Probe Input – 2 x 4mm Plug Over Range Indicator (Red) Attenuation Selector Switch Power Indicator (Red) External Power Supply Probe Output BNC Connector Included Accessories TT-SI NT7 TT-SI TL7 TT-SI GR2 TT-SI BN7 Man_7002_0919 www.testec.de... -
Page 9: Specifications
4 Specifications All specifications apply to the unit after a temperature stabilization time of 20 minutes over an ambient range of 25°C ± 5°C. TT-SI 7002 – order number 15175 Bandwidth 25 MHz @ x50 and x200 15 MHz @ x20... -
Page 10: Voltage Derating Curve
The derating curve of the absolute maximum input voltage in common mode is shown as follows: TT-SI 7002 Voltage Derating Figure: TT-SI 7002 Derating Curve 6 Cleaning This probe does not require any particular cleaning. If necessary, clean the case with a soft cloth. -
Page 11: Service And Warranty Information
This warranty is in lieu of all other representations or warranties expressed or implied and no agent or representative of Testec Elektronik GmbH is authorized to assume any other obligation in connection with the sale and purchase of this device. - Page 12 TT-SI 7002 Differential Probe User’s Manual © 2019 TESTEC Elektronik GmbH. All rights reserved. Unauthorized duplication of TESTEC documentation materials is strictly prohibited. Customers are permitted to duplicate and distribute TESTEC documentations for internal educational purposes Man_7002_0919 www.testec.de...
