SY-KLONE RESPASC Installation Instructions

RESPA CF/CFX/FF Heavy Debris Screen Installation Instructions
Sy-Klone part number: RESPASC
Purpose:
The RESPA-CF/CFX/FF Heavy Debris Screen prevents larger items that can
interfere with the fan blades from entering the unit. Recommended for landfill,
agriculture, and mining applications.
PRIOR TO INSTALLING RESPASC:
This installation requires both the Rain Cap and the Finger-Guard Screen. Both
items were included with the Revolution in a Box kit.
• Verify the RESPA unit has an installed rain cap.
• Remove the rain cap if installed and verify that the screened inlet is present.
• The screen will not work with the 4" ducted inlet.
If either or both of these are missing, please order the correct replacement part:
REVA-002 – Adapt The Revolution Kit, which includes all three inlet parts.
Rain Cap Installed.
Screened Inlet.
Stock code
RESPASC
ENGLIT0000268 00
Parts Included In Kit:
Description
RESPA Heavy Debris Screen
Tools Required:
#2 Phillips Screwdriver
¼" Socket Driver
¼" x 3" Socket Extension or longer
¼" Thin Wall Deep Socket.
Technical Support
www.sy-klone.com
support@sy-klone.com
(904) 448-6563 ext. 1310
Quantity
1
1
