- Page 1 ser’s s Man nual SG Global l Inc.
-
Page 2: Table Of Contents
OWER ABLES AND CCESSORIES 2 OVERVIEW ............................... 8 2.1 I ................................ 8 NTRODUCTION 3 DSG‐121‐VT HARDWARE INSTRUCTIONS ...................... 9 3.1 .............................. 9 RODUCT PPEARANCE 3.2 S ................................ 1 0 PECIFICATIONS 3.3 ... -
Page 3: Revision History
DSG-121-VT Revision History Version Description Date V1.0 First release 2018/01/20 V1.1 Revise 2019/04/21 V1.2 Update mounted description 2019/06/13 3 / 19... -
Page 4: Foreword
Please contact our technical department for relevant operation solutions if there is any problem that cannot be solved according to this manual. DSG reserves all rights of this manual, including the right to change the content, form, product features, and specifications contained herein at any time without prior notice. -
Page 5: Disclaimer
1.5 Limitation of Liability/Non-warranty For direct or indirect damage to this device or other devices of DSG caused by failure of conforming to this manual or the safety instructions on device label, DSG assumes neither warranty nor legal liability even if the device is still under warranty. -
Page 6: Precautions
DSG-121-VT 1.7 Precautions Pay attention to the product labels/safety instructions printed on silk screens. Do not try repairing this product unless declared in this manual. Keep away from heat source, such as heater, heat dissipater, or engine casing. Do not insert other items into the slot (if any) of this device. -
Page 7: Safety Instructions For Power Cables And Accessories
Proper power source only Start only with power source that satisfies voltage label and the voltage necessary according to this manual. Please contact technical support personnel of DSG for any uncertainty about the requirements of necessary power source. Use tested power source... -
Page 8: Overview
DSG-121-VT 2 Overview 2.1 Introduction Thank you for choosing DSG. It is our commitment to provide our valued customers with the embedded devices equipped with the state-of-the-art technology and the best product services. Computer enables the interaction between operators/users and applications, connects industrial control products such as wireless, transducer, battery inside, storage, etc. - Page 9 SG-121 DSG-1 21-VT THard dware Instru uctions s 3.1 P Product Appear rance FrontVi Back Vi 9 / 1...
-
Page 10: Specifications
DSG-121-VT 3.2 Specifications Processor RK-3288 , ARM Cortex-A17, Quad Core CPU,1.6GHz 2GB DDR3 Memory Flash 16GB EMMC Flash 12.1" TFT LCD Resolution 1024*768 24bit Color Display Colors 262k/16.2M Display Brightness 600cd/m2(Auto brightness by Light sensor) View Angle 85U/85D, 85L/85R Touch Screen... -
Page 11: Front View
SG-121 3.3 Inte erface I nstruct tions Front View w 3.3.1 Ligh ht-Sensor 5MpixsCa mera Micr rophone1 Microphone Speake Speaker-R Side View w 3.3.2 C Power In pe-C USB bug Interfac 3.4 Dim mension Whole devi ice Size: 2 238x323x3 36mm 3.5 But ttons ower/Slee ep/Wake b... -
Page 12: Interface Description
DSG-121-VT save the battery. Lock computer: Press the Power/Sleep/Wake button. Unlock computer: Press the Power/Sleep/Wake button, then drag the slider. Turn computer off: Press and hold the Power/Sleep/Wake button greater than 6 seconds. Turn computer on: Press and hold the Power/Sleep/Wake button until logo appears. -
Page 13: Wireless (Wifi And
DSG-121-VT SW3/RST: Reset button for reset mcu RT1050 and RK3288; SW5/RECOVERY: Recovery button for RK3288 recovery mode, when press this key and power on, RK3288 work with recovery mode. SW4/FAC: Factory button . Press FAC button and power on, MCU RT1050 and RK3288 recovery factory data. - Page 14 SG-121 didn’t turn it on. Power&Si ignal Inter rface 3.6.9 here with a M14 Int terface co ontain DC Power IN N, Charger control an nd RS232 commu unication. he M14 In nterface de efined as b below: 1 – GND (RS232 2 –...
-
Page 15: Instructions
DSG-121-VT has been pre-loaded with Android image, so that the system can run MFG toolsto updatethe system image, please reference to SW-UM. DSG-121-VT has been mounted on the golf vehicle with a VESA through the back hole; supplied by golf vehicle battery. -
Page 16: Tips
In the aim of avoiding accidents as far as possible, it is not allowed to replace the system or change components unless with permission and certification. Please contact the technical department of DSG or local branches for help. Pay attention to caution signs. - Page 17 DSG assumes no responsibility of possible missing contents and information, errors in contents, citations, examples, and source programs. DSG reserves the right to make necessary changes to this manual without prior notice. No part of this manual may be reprinted or publicly released in forms of photocopy, tape, broadcast, e-document, etc.
- Page 18 It’s not allowed to disassemble the product. It is not allowed to replace the system or change components unless with permission and certification. Please contact the technical support department of DSG or local branches for help. RF Exposure Statement This equipment must be installed and operated in accordance with provide...
- Page 19 DSG-121-VT L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Note: The device for operation in the band 5150–5250 MHz is only for indoor...
