AS80CA11A
1080P IP Camera
General Introduction
The IP Camera is designed to monitor the premise where it is installed at in real
time, and send the images to the Gateway. The recording function will be
activated if an event is triggered under warning conditions. Its great compatibility
with our U-Net family security products makes it suitable for smart home cloud
based platform.
Product Layout
Front view
Rear view
1
Microphone
3
IR LED (hidden)
5
Reset/WPS button
7
Micro-SD card slot
Installation Instructions
Side view
2
Lens
4
LED indicator
6
Power jack
Connecting camera to home Wi-Fi
The camera first needs to connect to your home Wi-Fi network. There are two
methods to do this
Method 1: By QR code setup. A smartphone installed with ELRO Smart Home
Alarm App is required.
1. On the ELRO Smart Home Alarm App, go to System page and tap the QR
code icon on the top bar.
2. Enter your home Wi-Fi network and your Wi-Fi password, if any.
3. The App will then generate a large size QR code image. Leave the App on
that page.
4. Power up the camera using the supplied power adaptor and wait for a
musical tone. This usually takes about 30 seconds.
The musical tone indicates the camera is ready to scan the QR code created
earlier by the App.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ELRO AS80CA11A
Summary of Contents for ELRO AS80CA11A
-
Page 1: General Introduction
Method 1: By QR code setup. A smartphone installed with ELRO Smart Home based platform. Alarm App is required. 1. On the ELRO Smart Home Alarm App, go to System page and tap the QR Product Layout code icon on the top bar. - Page 2 5. Place the QR code at about 10cm in front of the camera lens. be heard. Binding with Smart Home 1. Log into the Smart Home account from a web browser. 2. Select “System”, then “Add a device”. 6. If the QR code scan is successful, a musical tone will be heard. The camera will then attempt to connect to the home network.
- Page 3 Playback recorded videos 1. To display recorded videos, go to VIDEO page. All videos are displayed with recording date and video duration. 2. Click on any image to play the video. Note: If the web page indicates camera is not reachable, it could be the Wi-Fi information set up earlier might be incorrect.
-
Page 4: Mounting The Camera
Mounting the camera 1. Using a sharp object, press and hold the reset button behind the camera for more than 10 seconds then release. The camera can be placed on table top, mounted on a wall or ceiling. When mounting on a wall or ceiling, use supplied screw and wall plugs to secure the camera in place.
