PROMENTUM™
SWITCH AND CONTROL MODULE
INSTALLATION GUIDE
ATCA-2210
007-02524-0004 • September 2008
Copyright © 2006-2008 by RadiSys Corporation. All rights reserved.
RadiSys is a registered trademark and Promentum is a trademark of RadiSys Corporation. Linux is a registered trademark of Linus Torvalds. AdvancedTCA and ATCA are
registered trademarks of PCI Industrial Computer Manufacturers Group. Procomm Plus and Symantec are registered trademarks of Symantec Corporation. All other
trademarks, registered trademarks, service marks, and trade names are the property of their respective owners.
This document describes how to install and to set up the
Promentum™ ATCA-2210 switch and control module
(SCM).
Obey ESD precautions
W
!
Obey the electrostatic discharge (ESD)
ARNING
procedures described at
www.radisys.com
the product.
Electrostatic discharge can cause permanent damage to
static-sensitive components in this product. Important ESD
procedures include:
Keep the product in its ESD shielding bag until a step
tells you to remove it.
Put on a grounded wrist strap before you move near or
touch the product.
Install the product only in a grounded work area.
Prepare for installation
The installation of the SCM requires the following:
An AdvancedTCA® (ATCA®) shelf, such as a RadiSys
ATCA-6000, ATCA-6006, ATCA-6014, or ATCA-6016
shelf
A 9-pin D-shell to RJ-45 serial port cable (shipped
with the SCM)
A standard crossover Ethernet cable
Adequate ventilation for the shelf
Install SFPs or XFPs on the SCM
The SCM comes with sockets for small form-factor
pluggable (SFP) and 10 Gigabit small form-factor
pluggable (XFP) transceiver modules. If SFPs and XFPs
are installed, they can provide external connections to the
Ethernet interfaces. The sockets are accessed from the
faceplate of the SCM.
when you install
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for RadiSys RadiSys ATCA-2210
-
Page 1: Prepare For Installation
RadiSys is a registered trademark and Promentum is a trademark of RadiSys Corporation. Linux is a registered trademark of Linus Torvalds. AdvancedTCA and ATCA are registered trademarks of PCI Industrial Computer Manufacturers Group. Procomm Plus and Symantec are registered trademarks of Symantec Corporation. All other trademarks, registered trademarks, service marks, and trade names are the property of their respective owners. - Page 2 Installation Guide Configuration recommendations Standard SCM configurations come without SFP or XFP transceivers installed. To protect the internal components of the SCM, transceivers or filler plugs must be installed in all empty sockets: The Base Ethernet configuration supports up to four SFP transceivers and one XFP transceiver, with filler plugs installed in unused sockets.
- Page 3 Filler plug installation If XFP or SFP transceivers are removed, install either replacement transceivers or filler plugs in the sockets to protect the internal components of the SCM. Additional filler plugs can be ordered from the applicable manufacturer; for a list of tested and qualified transceivers and filler plugs, see the Support section of the RadiSys Web site at www.radisys.com.
-
Page 4: Table Of Contents
Installation Guide SCM installation checklist The following table describes the possible installation scenarios for the SCM, the appropriate tasks to complete for the scenarios, and the order to complete the tasks: SCM is being... Configuration Installed in a RadiSys shelf Standard configuration. -
Page 5: Install The Scm In The Shelf
Install the SCM in the shelf 1. Follow ESD precautions and make sure you are adequately grounded before handling the transceivers and the SCM. 2. Remove the SCM from its antistatic bag. 3. Open both ejector latches outward. Never force open an ejector latch. Press the ARNING inner latch all the way in before you pull out the handle. -
Page 6: Connect To The Scm
Installation Guide Connect to the SCM The SCM can be accessed by an external computer through the serial and the Ethernet maintenance ports. Use the serial port to perform diagnostic and verification procedures or to enable or disable the Shelf Manager. Use the Ethernet maintenance port to connect the SCM to the network and to perform configuration procedures. -
Page 7: Verify Switch Operation
Verify switch operation Use these steps to view port status and to enable ports on the Base Ethernet and the Fabric Ethernet switches. View port status 1. Verify you are at this prompt. ATCA-2210# If you are not at the appropriate prompt, see how to get there. - Page 8 Installation Guide Enable all ports 1. Verify you are at the applicable switch prompt. Switch Base Ethernet Fabric Ethernet If you are not at the appropriate prompt, see 2. Enter this series of commands to enable all ports. A. configure B.
- Page 9 B. Enter the specific port (interface) number to enable. The s variable represents the specified slot. The p variable represents an individual port within the group of ports for the specified slot. interface <s/p> Where have the following values: Base Ethernet switch interfaces ATCA-6000 backplane slots ATCA-6006 backplane slots ATCA-6014 backplane slots...
-
Page 10: Verify Shelf Management Operation
Installation Guide 3. Enter the exit command again, to log off the SCM. 4. If you have two SCMs installed, repeat these steps on the other SCM. Verify shelf management operation These steps confirm that shelf management is operating when the SCM is installed in a RadiSys shelf. If the SCM is installed in a non-RadiSys shelf, shelf management is not available. - Page 11 6. To determine the version of SCM’s on-board Shelf Manager, enter: rsys_debug -h 7. After determining the version, enter the appropriate command. For version Enter this command 0.96 or below rsys_debug 0.97 or above rsys_debug -i 127.1 8. Once the software tool has completed its initialization, the host address is displayed. Make a note of this address for an upcoming step.
-
Page 12: Enable The Shelf Manager On The Scm
Installation Guide Enable the Shelf Manager on the SCM If you plan to remove an SCM from a non-RadiSys shelf and reinstall it in a RadiSys shelf, enable the on-board Shelf Manager before removing the SCM. Important: If the SCM is removed from the non-RadiSys shelf without having its on-board Shelf Manager enabled, you will need to install the SCM in a shelf (RadiSys or non-RadiSys) that already has an active Shelf Manager running. -
Page 13: Where To Go From Here
13. The following text displays: Get SCM ShMgr Mode - Enter address (in hex): Enter the same host address you entered for this message displays: SCM ShMgr Mode: Enabled 14. Enter q to exit the rsys_debug mode. 15. Remove the SCM and reinstall it in a RadiSys shelf. For removal instructions, see the Switch and Control Module Reference. -
Page 14: Where To Get More Product Information
Installation Guide Where to get more product information Please visit the RadiSys Web site at Downloads (manuals, release notes, software, etc.) are available via the Technical Support Library product links at www.radisys.com/support www.radisys.com for product information and other resources. or the product pages at www.radisys.com/products.
