VECTOR 50
Gebrauchsanweisung
Operating instructions
Manuel d'instructions
Instruzioni d'uso
Instrucciones de uso
Gebruiksaanwijzing
Руководство по применению
Instrukcja obsługi
Eksploatacijos instrukcija
Lietošanas instrukcija
Uputstvo za upotrebu
Návod k použití
Manual de utilizare
Ръководство за употреба
BG
Használati útmutató
HU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vector 50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sola Vector 50

Summary of Contents for Sola Vector 50

  • Page 1 VECTOR 50 Gebrauchsanweisung Operating instructions Manuel d’instructions Instruzioni d‘uso Instrucciones de uso Gebruiksaanwijzing Руководство по применению Instrukcja obsługi Eksploatacijos instrukcija Lietošanas instrukcija Uputstvo za upotrebu Návod k použití Manual de utilizare Ръководство за употреба Használati útmutató...
  • Page 2 Included in delivery with the Vector 50 1. Laser distance measurement instrument 2. Belt pouch 3. AAA batteries...
  • Page 3 2.1 Function buttons 2.1 Display...

  • Page 4: Table Of Contents

    (original version) About this manual Congratulations on the purchase of your new Vector 50! You have acquired a SOLA measurement instrument, which can make your work easier, faster and more precise. To utilize the complete functionality range of this measurement instrument, and to ensure a safe operation, please observe the following instructions: •...

  • Page 5: General Information

    1. General information 1.1 Signal words and their meaning 1.2.2 Symbols DANGER Read the operating For an imminent danger that could lead to serious manual before use injury or death. WARNING Batteries and devices must not be For a possibly dangerous situation that could lead disposed of with household waste to serious injury or death.

  • Page 6: Description

    2. Description 2.1 Function Buttons 1 Vial 2 Display 3 ON/Measure button 4 Add, subtract/signal 5 Function button 6 OFF/Delete button 7 Belt holder 2.2 Display 1 Measured values 2 Mathematical sign 3 Surface, volume, indirect measurement 4 Measured value display 5 Battery status 6 Measurement edge 7 Unit...

  • Page 7: Technical Data

    3. Technical data 3.1 General Measurement range 0.15–50 m* Accuracy ± 1.5 mm** Protection rating IP 42 Laser class Laser type 650 nm, < 1 mW Laser auto-shutdown 45 s Instrument auto-shutdown 180 s Operating duration up to 5000 measurements*** Battery type 2 x AAA 1.5 V Operating temperature 0–40 °C Storage temperature...

  • Page 8: Safety Instructions

    Inadequate safeguarding at the installation site. 4.3 Utilization limitations The VECTOR 50 is suitable for continuous use in an atmosphere which can be inhabited by humans. Do not operate the product in explosion-prone or corrosive environments. Inform the local safety authorities and safety experts before working in hazardous environments, in...
  • Page 9 CAUTION A fall, longer storage, transportation or other mechanical effects can lead to erroneous meas- urement results. Check the unit for damage before use. Do not use damaged equipment. Repairs must only be performed by SOLA. 4.4.2 Batteries DANGER Mechanical damage can cause batteries to leak, explode or catch fire or trigger the release of toxic substances.
  • Page 10 WARNING High ambient temperatures and immersion into liquids can cause batteries to leak, explode or catch fire or trigger the release of toxic substances. Protect batteries and rechargeable batteries from mechanical damage during transport. Do not overheat batteries and rechargeable batteries or expose them to fire. Avoid the ingress of moisture into batteries and rechargeable batteries.
  • Page 11 4.5.1 Interference with other devices by VECTOR 50 Although the product meets the strict requirements of the relevant directives and standards, SOLA cannot completely exclude the possibility of interference with other devices (for example, when using the product in combination with third-party devices, such as field computers, personal computers, wireless devices, mobile phones, certain cables or external batteries).

  • Page 12: Laser Safety / Classification

    Looking into the laser beam may be hazardous to the eye. Do not look into the laser beam. Do not aim the laser beam at other people. Labelling on the device: Made in PRC www.sola.at Do not remove the type plate!

  • Page 13: Getting Started

    6. Getting Started 6.1 Operation with batteries 1. Open the battery compartment cover on the rear side of the device. 2. Insert the batteries into the instrument, observing the correct polarity. 3. Close the battery compartment cover. Only use type 1.5 V AAA batteries! Remove the batteries if the instrument is not used for an extended period.

  • Page 14: Operation

    7. Operation 7.1 Getting Started 7.1.1 Switching the Instrument On and Off Hold down the ON/Measure button to switch the laser instrument on. Hold down the OFF/Delete button for 2 seconds to switch the laser instrument off. 7.1.2 Back Press the OFF/Delete button once to undo the last action. Press the OFF/Delete button twice to exit the current function and return to individual measurement mode.
  • Page 15 7.2.3 Continuous Measurement 1. Switch on the laser instrument. 2. Direct the laser point at the target. 3. Press the Min/Max and continuous measurement button. The laser instrument measures the distance and shows it on the bottom line of the display. 7.2.4 Area Measurement 1.
  • Page 16 7.2.5 Volume Measurement 1. Switch on the laser instrument. 2. Press the Function button until the display for volume measurement appears. 3. Measure the length, the width, and then the height separately using the individual measurement method. The laser beam remains switched on between the three measurements. Once the third measurement is complete, the volume is automatically calculated and shown on the bottom line of the display.
  • Page 17 CAUTION The three points measured must run in a line and the second measurement must be taken at a right angle to the measured surface; otherwise measured values may be incorrect. 7.2.7 Addition 1. Switch on the laser instrument. 2. Direct the laser point at the target. 3.

  • Page 18: Maintenance, Storage And Transportation

    8. Maintenance, storage and transportation 8.1 Cleaning Wipe off the dirt with a soft damp cloth. Check the outlet openings of the laser regularly, and thoroughly clean them if necessary. Do not touch the glass with your fingers. Do not use aggressive cleaning agents or solvents. Do not immerse the device in water! Clean and dry wet equipment, accessories and transport containers prior to packaging them.

  • Page 19: Delivery Contents And Accessories

    9. Delivery contents and accessories 9.1 Included in delivery with the Vector 50 1 Laser distance measurement instrument 2 batteries 1 Belt pouch 9.2 ACCESSORIES (optional) LB RED laser protection goggles ZS RED target Further information on accessories can be found at www.sola.at...

  • Page 20: Troubleshooting

    10. Troubleshooting Error Possible Cause Remedy Distance outside of the Stay inside the measurement range. measurement range. The reflected signal is Measure using a more too weak. reflective surface. Range outside the Use the OFF/Delete button display. to reset to zero. Calculation error in Carry out measurement again.

  • Page 21: Disposal

    - must not be disposed of with household waste. Dispose of the device and the accessories properly. Observe the country-specific disposal requirements. Your SOLA dealership will accept returned batteries as well as old equipment, and will ensure proper disposal. Only for EU countries...

  • Page 22: Manufacturer's Guarantee

    12. Manufacturers’ guarantee "The manufacturer warrants to the original purchaser stated on the guarantee card, freedom from defects of the device for a period of two years, with the exception of batteries, from such time as the device is handed over. The guarantee is limited to repairs and/or replacements at the manufacturer’s discretion. Defects which are caused through improper handling by the purchaser or third parties, natural wear and optical flaws that do not affect the usability of the equipment, are not covered by this guarantee.

  • Page 23: Ec Conformity Declaration

    Konformitätserklärung Declaration of conformity Déclaration de conformité Wir / We / Nous SOLA-Messwerkzeuge GmbH, A-6840 Götzis, Austria erklären in alleiniger Verantwortung, dass das Produkt(e) declare under our sole responsibility that the Product(s) déclarons sous notre seule responsabilité que le(s) produit(s) VECTOR 50 auf das sich diese Erklärung bezieht, mit den folgenden Normen übereinstimmt.
