Ecofit DuraStreet Series Installation Instructions Manual

Installation Instructions

Safety

• The DuraStreet LED light engine is ETL listed and should be installed in accordance with the National Electric Safety
Code (NESC) and local regulations.
• Turn power off prior to installation and during maintenance.
• Installation and service must be performed by qualified personnel.
• Installation of this product confirms that the installer has read and accepts EcoFit's Terms & Conditions. Section 2 of
these Terms & Conditions provides important information about the safe installation this product (see Exhibit 1).

Notices

• Customer is solely responsible for hiring or training qualified individuals for safe and proper installation of EcoFit
products. EcoFit expressly disclaims and customer assumes any liability for injuries or damages caused during
installation due to unqualified installation personnel, failure to heed warnings provided herein, or other improper or
unsafe installation of the EcoFit products.
• Prior to any installation, customer or its agent must perform a thorough inspection of the existing luminaire, and
determine, after taking into account the luminaire' shape, size and weight, that DuraStreet light engines can be safely
installed in the luminaire. Consistent with prudent and best practices for luminaire maintenance, the luminaire should
be checked for any physical impairments, such as loose connections, cracks, rust, significant wear or deterioration of
any luminaire part, or any other indications that the luminaire may not be fit to safely house EcoFit's products. If any
problems are found, then the DuraStreet unit should not be installed in the luminaire, and the luminaire should be
serviced—or replaced with a new luminaire—before installation.
• In the event the customer or customer's agent cannot safely install EcoFit's products without materially deviating from
these instructions, customer or its agent shall immediately contact EcoFit to find a mutually agreeable solution. As
more fully discussed in EcoFit's Terms & Conditions (see Exhibit 1), any deviation from these instructions may void
the limited warranty, and EcoFit disclaims any liability for damage or injuries resulting from a deviation from these
instructions.

Installation

The DuraStreet light engine is installed in existing roadway
luminaires. Use a bucket truck or other authorized lifting
equipment to reach the luminaire.
Step 1: Open The Door of Your Existing
Luminaire (Figure 1)
• Release the latch at the front of the luminaire.
• Almost all roadway luminaires use some kind of simple,
toolless, spring-loaded latch. The latch is typically wire-
formed, cast, or constructed of a similar material.
DuraStreet ®
F 1: Open the door of the existing luminaire.
IGURE
Page 1
Series LED Light Engine
Typical
Roadway Luminaire
(By Others)
