TrickleStar 505TT-US-W Instruction Manual

WEEKLY TIMER, 15A/1875W
505TT-US-W
INSTRUCTIONS (ENGLISH)
Introduction
Thank you for purchasing this TrickleStar
provides enhanced controls
consumption of appliances, which do not include timing controls.
This product is suitable for a wide range of appliances including:
heaters, stand-alone air conditioning units, fans, water pumps, hot
water urns, water coolers, photocopiers, pool pumps, signage etc.
MO TU WE TH FR SA SU
COUNT DOWN
Day
Button
DAY
CLOCK
Control
Socket #1
Clock
Button
Features
The Product has the following key features:
Up to 8 ON and OFF programs a day / 56 ON and OFF
•
programs per week.
Option to program individual days or 8 different weekday
•
groups
Minimum switching period one minute
•
Manual override button
•
Random ON/OFF security feature
•
Countdown feature
•
12 hour AM/PM display.
•
Summer/Winter time changeover
•
Rechargeable backup battery
•

Getting Started

The product has an easy to use LCD display:
TM
product. This product
to reduce wasteful
LCD
Display
AUTO MANUAL Hour Button
Minute Button
HOURS MIN
Reset
RESET
COUNT PROG.
DOWN
Control
Socket #2
MANUAL
Manual
Button
Program
Button
Buttons
DAY
HOURS
MIN.
CLOCK
PROG.
MANUAL
RESET
Plug the product into a wall outlet and plug an appliance to be
controlled into the Control Socket.
energy
NOTE:
The product contains a battery, which stores the settings and
drives the Display. If the display is off when you plug in the product
to a wall receptacle, then allow the product to charge for a short
time and the text will gradually appear.
Set Time
The product has a Summertime/Wintertime changeover function.
The product is per default (and after reset) in Wintertime. If you
purchase this unit during the summertime press the 'HOURS' and
'MIN' buttons simultaneously to switch to summertime and "S" will
appear on the Display.
To set the weekday and clock:
1. Press-and-hold the 'CLOCK' button
2. Press the 'DAY' button to set the weekday
3. Press the 'HOUR' button to set the hours
4. Press the 'MIN' button to set the minutes
5. Release the 'CLOCK' button
If the 'DAY', 'HOURS" or 'MIN' button is pressed for more than 1
second the value will increase continuously while button is
pressed.
: Sets weekday
: Sets hours
: Sets minutes
: Enables clock/weekday setting
: Enables Timer Programming
: Manual ON/OFF of Control Socket
: Resets product to factory default
505TT-US-W
MO TU WE TH FR SA SU
COUNT DOWN AUTO MANUAL
DAY HOURS MIN
RESET
CLOCK COUNT PROG.
DOWN
MANUAL
