Summary of Contents for Saxco RG-AT40S-I/O

  • Page 1 MANUAL RG-AT40S-I/O...

  • Page 2: Table Of Contents

    Content 1 Techni c al Param e t ers 2 Components 3 Installation step 3-11 3.1 Installation of bottom plate 3.2 Installation of bottom plate 3.3 Installation of pull bar 3.4 Installation of pull bar 3 .5 Installation of push bar 3 .6 Installation of push bar 3.7 Finished installation 3.8 Machanism and cover installation...

  • Page 3: Technical Parameters

    1.Technical Parameters Dimensions： 515*80*115mm(LWH) Weight： 8kgs Ambient temperature： -20 ~ +50℃ Operation voltage： AC 200V -250V Power supply external consumer： 24V DC (±10%),3A Door opening angle： Max 115° Opening speed： 45°/S Closing speed： 45°/S Hold-open time： 0-60S Protection class： IP21 mm= Door width Suitable range kg= Door weight...

  • Page 4: Components

    1. Components Rightside cover Controller Motor Leftside cover Pull bar Transformer 220V input RG-AT40S-I/O Bottom plate Pull bar Cover Pull guider Mechanism...

  • Page 5: Installation Of Bottom Plate

    Installation step Installation of bottom plate Pull bar type power liner sensor liner As the picture showing, fix the bottom plate on the frame with eight countersunk head screw. frame bottom plate Operator at right position. power liner sensor liner As the picture showing, fix the bottom plate on the frame with eight countersunk head screw.

  • Page 6: Installation Of Bottom Plate

    Installation step Installation of bottom plate Push bar type sensor liner power liner As the picture showing, fix the bottom plate on the frame with eight countersunk head screw. frame bottom plate Operator at right position. sensor liner power liner As the picture showing, fix the bottom plate on the frame with eight countersunk head screw.

  • Page 7: Installation Of Pull Bar

    3.Installation step 3.3 Installation of pull bar guider 1.Open the door to 90 degree before installation，put the slider of pull bar into groove 2.Fix the pull bar installation plate according to the picture 3. Adjust the the position of slider installation plate，make sure the wheel is at the middle of groove as the picture shown 4.Keep the position of installation plate，tighten the first screw at the axis of door 5.Close the door ，repeat the step 3，tighten the second screw at another side...

  • Page 8: Installation Of Pull Bar

    Installation step Installation of pull bar guider A. Right position Fix the pull bar on door leaf with 3 pcs self-tapping screw. Door leaf Adjust the opening angle by position stopper. position stopper...

  • Page 9: Installation Of Pull Bar

    Installation step Installation of pull bar guider B. Left position Fix the pull bar on door leaf with 3 pcs self-tapping screw. Door leaf Adjust the opening angle by position stopper. position stopper...

  • Page 10: Installation Of Push Bar

    Installation step Installation of push bar Fix the bottom of push bar to door leaf Adjust the push bar lenght by two screw according to the door frame’s depth(L).

  • Page 11: Installation Of Push Bar

    Installation step Installation of push bar B. Left position Fix the bottom of push bar to door leaf Adjust the push bar lenght by two screw according to the door frame’s depth(L).

  • Page 12: Installation Step

    3. Installation step Finished installation Pull bar: Door leaf open toward inside (same direction as operator) operator Push bar: Door leaf open toward outside (same direction as operator) operator...

  • Page 13: Machanism And Cover Installation

    3. Installation step Mechanism installation Hang the mechanism on the fixed base cover with screws. Assemble and disassemble of the mechanism up cover.

  • Page 14: Wired Digram

    4. Wired diagram 4.1 Terminal details +24V Synchronous(out) code value Synchronous(in) +12V 1 2 3 1: LED on/off 2: Master door selector Interlock(out) 3: L/R switch OPEN-A Interlock(in) Test: In double open mode,test TEST FULL LOCK button is disabled on salve E-lock+ controller LEARN...

  • Page 15: Connection Of Commonly Used And Special Function

    Wired Diagram Inter-lock 16.inter-lock signal IN 16.inter-lock signal IN 14.inter-lock signal OUT 14.inter-lock signal OUT Door A Door B Synchronous 13.Synchronous IN 13.Synchronous IN 11.Synchronous OUT 11.Synchronous OUT Door A Door B In single open mode： bridge connect terminal 11 and 13 13.Synchronous IN 11.Synchronous OUT 24G Microwave sensor...
  • Page 16 Wired Diagram AK04 Access keypad 3. +12V 4. GND +12V 9.OPEN-B D-IN OPEN ALARM 10.COM Wiring connection of electronic bolt lock (Attention：Dont connect magnetic lock directly without Transformer or Ups) 18. GND (black) Electronic lock+ Anti-clamp sensor when opening 24. Anti-clamp 22.
  • Page 17 Wired Diagram Operation of remote control FC04B: Always open Close door & Unlock C: Open and close one time Full lock Add the remote ： press the learning button on controller till the indicator turn from green to red， then release the learning button and press A button on remote， the indicator turn from red to green alternately 3 times，...

  • Page 18: Led Display Feedback

    5. LED display feedback Single opening Double opening LED display Details LED display Details Dr11 No problem. Dr12 Master door Terminal 11 and 13 are not Dr13 Slave door connected.(They should be Over current prote on for Dr12 or Dr13 Er01 connected when...
