Pei tel PTCarPhone 5 Series Installation Instructions

Precautionary Measures during Installation

CAUTION: Non-compliance with these instructions can cause damage to the device
and to the vehicle.
Qualified installation personnel
The device must only be installed in the vehicle and serviced by qualified specialists.
! Consequences of incorrect installation
Incorrect installation can cause damage to the vehicle. Incorrect assembly or ser-
vice can have hazardous consequences and can void the warranty and possibly the
operating permit of your vehicle.
Airbag
With vehicles that are equipped with an airbag, remember that the airbag fills with
a strong force. Do not install any components in the area impacted by the filled
airbag.
Antennas
Before start-up of the device, the GSM or UMTS antenna and the GPS antenna, for a
device with integrated GPS module, must be connected (antennas are not included
in the scope of supply). The device must not be operated without antenna(s), since
this can lead to the destruction of the device.
Connection to the power supply of the vehicle
In some cases settings must be done in modern vehicles after attaching the bat-
tery. Absolutely be sure to refer to the operating manual of your vehicle for this.
Environmental influences: Water and dust
The PTCarPhone and all accessories are neither dustproof nor waterproof. Make
sure that the PTCarPhone is always protected from moisture and from water pene-
trating the vehicle. Prevent penetration of dust particles in the housing by cleaning
regularly.
More information is available in "PTCarPhone 5 Series Operating Manual" at:
http://www.ptcarphone.de/en/downloads
www.ptcarphone.de
A member of the peiker group
Article number: 6053-085-024-00 - 06/2016
Installation Instructions
Upgrade Kit for the
PTCarPhone 5 Series
For PTCarPhone, PTCarPhone II,
PTCarPhone 3 and PTCarPhone 4
ENGLISH
