TERRAKOTTA-BRUNNEN
BEDIENUNGSANLEITUNG
10022936

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 10022936 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blumfeldt 10022936

  • Page 1 TERRAKOTTA-BRUNNEN BEDIENUNGSANLEITUNG 10022936...
  • Page 2 Sehr geehrter Kunde, zunächst möchten wir Ihnen zum Erwerb Ihres Gerätes gratulieren. Bitte lesen Sie die folgenden Aufbau- und Anwendungshinweise sorgfältig durch und befolgen Sie diese um möglichen technischen Schäden vorzubeugen. Sicherheitshinweise • Um die Gefahr von Stromschlägen zu reduzieren entfernen Sie keine der Abdeckungen. Das Gerät enthält Teile, die dem Benutzer nicht zugänglich sind.
  • Page 3: Technische Daten

    Technische Daten Artikelnummer 10022936 Leistung Solar Panel 2W Betriebsspannung 6V DC Maximale Wasserförderung 200 l/std Maximale Förderhöhe 0,8m Wasser Projektionshöhe 0,4m Kabellänge 5m Batterie 3,7V, 2000mAH Lieferumfang: Schlauch & Stopfen Schalen (x3) Große Schale Gestell Solar-Panel LED mit Kabel Oberer Krug...
  • Page 4 Aufbau Schritt 1 Stellen Sie das Gestell auf eine ebene und wasserbeständige Oberfl äche. Schritt 2 Stellen Sie die große Schüssel in den unteren großen Ring, die drei „Töpfe“ in die mittleren Ringe und den Krug in den oberen Ring. Schritt 3 Führen Sie den Schlauch von der großen Schüssel druch die kleinen Ringe bis zum Krug nach oben.
  • Page 5 Aufbau Schritt 5 Verbinden Sie die Pumpe sowie den LED-Ring mit dem Solar-Panel (beachten Sie die Aufschrift an den Anschlüssen auf der Rückseite des Solar-Panels. Sie können den LED-Ring über den Schlauch ziehen, oder beliebig platzieren. Wählen Sie für das Solar-Panel einen geeigneten, d.h. der Sonne ausgesetzten und im besten Falle ihr zugewandten Aufstellort.
  • Page 6: Wartung & Pfl Ege

    Wartung & Pfl ege Solar Panel Das Solar Panel sollte regelmäßig mit einem weichen Tuch abgewischt werden, damit die Lichtdurchläs- sigkeit gewährleistet bleibt. Nutzen Sie keine scheuernden Materialien oder Reinigungsmittel Pumpe Falls die Pumpe nach einer Weile nicht mehr die gewohnte Durchlaufl eistung erbringt oder aufhört zu arbeiten, schauen Sie nach, ob Sediment, oder Schmutz Filter oder Pumpe verstopft.
  • Page 7: Important Safety Advice

    Dear Customer, Congratulations on purchasing this product. Please read and follow these instructions, in order to avoid damaging the item. We do not cover any damages that may arise from improper use of the item or the disregard of the safety instructions. Important Safety Advice •...
  • Page 8: Technical Data

    Technical Data Item # 10022936 Solar Panel Power 2W Input Voltage 6V DC Water lift (max.) 200 l/h Water lift height 0.8m Projection height 0.4m Cable length 5m Battery 3.7V, 2000mAh Scope of delivery: Hose & plug Pots (3x) Big bowl...
  • Page 9 Assembly Step 1 Place the rack on an even and water resistant surface. Step 2 Place the big bowl into the lower ring, place the pots into the three middle-sized rings and put the tankard into the upper ring. Step 3 Lead the hose up through the small rings, starting in the bowl, attaching it with the plug to the tankard (see depicted above).
  • Page 10 Assembly Step 5 Connect the pump as well as the LED ring with the solar panel (please note the correspondingly labeled connection jacks on the rear of the solar panel). You can draw the LED ring over the hose, or place it anywhere else. Choose a suitable (i.e.
  • Page 11: Maintenance

    Maintenance Solar Panel The panel should be cleaned periodically with a soft tissue. Regular cleaning of the panel is advised to maintain optimum conversion of the sun’s energy into direct current. Pump lf, after a period of time, the pump starts to lose power or stops working check for the build up of sedi- ment, scale or dirt in the fi...
