OPERATING INSTRUCTIONS AND SPARE PARTS LISTS
U
Hi gh Sp eed M ot or
MODEL 173271 (115V/1/ 60HZ)
MODEL 173272 (230V/1/50-60HZ)
BETTCHER
Industries, Inc.
LTRA
MODEL UN-99
For Use With All Current
Electric Whizard
D
RIVE
®
Trimmers
MANUAL #173299
Issued : April 30, 1999
TMC #796

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra Drive UN-99 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bettcher Ultra Drive UN-99

  • Page 1 BETTCHER Industries, Inc. OPERATING INSTRUCTIONS AND SPARE PARTS LISTS LTRA RIVE Hi gh Sp eed M ot or MODEL UN-99 For Use With All Current ® Electric Whizard Trimmers MODEL 173271 (115V/1/ 60HZ) MANUAL #173299 MODEL 173272 (230V/1/50-60HZ) Issued : April 30, 1999...
  • Page 2 The Information Provided In These Operating Instructions Are Important To Your Health, Comfort And Safety. For Safe And Proper Operation, Read This Entire Manual Before Using This Equipment. Copyright  1999 By Bettcher Industries, Inc. All Rights Reserved Original Instructions Page i...

  • Page 3: Table Of Contents

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Table Of Contents SECTION 1.0 Machine Specifications SECTION 2.0 Designated Use Warning Recommended Operation SECTION 3.0 Function Machine Function Description Safety Recommendations And Warnings SECTION 4.0...
  • Page 4 ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Table Of Contents (Continued) SECTION 7.0 Maintenance Controller Assembly Hanger Assembly Belt Drive Assembly Enclosure/Frame/Motor Assembly Preventative Maintenance SECTION 8.0 Cleaning SECTION 9.0 Spare Parts List...

  • Page 5: Machine Specifications

    INDUSTRIES, INC. Rev. April 17, 2015 SECTION 1.0 Machine Specifications ® The Bettcher Whizard Ultra Drive High Speed Motor is designed with the highest possible standards for safety in addition to high production efficiency. ® The Whizard Ultra Drive High Speed Motor Assembly described in this Operation Instruction has been tested by an independent and certified body, Underwriter’s...

  • Page 6: Designated Use

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 SECTION 2.0 Designated Use Warning W A R N I N G ® WHIZARD TRIMMERS ARE USED FOR REMOVAL OF FAT AND TISSUE, THE RECOVERY OF LEAN MEAT FROM FAT AND AS A UNIVERSAL CUTTING TOOL IN THE MEAT INDUSTRY.

  • Page 7: Recommended Operation

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Recommended Operation ® The Whizard Ultra Drive High Speed Motor Assembly has been designed for use ® with the following Whizard Trimmers : Model...

  • Page 8: Function

    The Whizard Ultra Drive High Speed Motor has been designed to be used with ® all electric driven Bettcher Whizard Trimmers plus UN84 Quick Release Flex Shafts and Casings. A custom belt drive and controller provides higher speed which provides faster blade speed.
  • Page 9 ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Safety Recommendations And Warnings (Continued) W A R N I N G ALWAYS DISCONNECT THE POWER AND REMOVE THE TOOL FROM THE FLEX SHAFT PRIOR TO SERVICING.

  • Page 10: Safety Features

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 SECTION 4.0 Safety Features Strain relief design allows motor to be free-swinging. The machine has an interlock on the handpiece hanger that prevents hanging the handpiece while the motor is running or turning the motor on while the handpiece is in the hanger.
  • Page 11 For further details on the ergonomic design considerations to the work station, ® please refer to the Whizard Trimmer Ergonomic Manual. Copies may be obtained by making the request to Bettcher Industries at the contact locations listed in the back of this manual. CASING SIZE Small Diameter-Short 12” 12”...

  • Page 12: Mounting Drive Unit

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Mounting Drive Unit ALWAYS REM OVE THE FLEX SHAFT/ CASING ASSEM BLY AND TRIM M ER FROM THE DRIVE UNIT PRIOR TO MOUNTING OR REMOVING THE DRIVE UNIT.

  • Page 13: Instructions For Operation

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 SECTION 6.0 Instructions For Operation Storing Trimmer (Refer To Figure #3A) To place the Trimmer in the hanger, swing the Latch with your left hand to the left and lift up the Handpiece Bracket to the full raised position (the Latch and Bracket are attached to one another).

  • Page 14: Removing Trimmer

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Removing Trimmer (Refer To Figure #3B) To remove the Trimmer from the hanger, firmly grasp the handpiece by it's handle with your dominant hand and swing the Latch with your opposite hand to the left and lift the Bracket to its fully raised position, then carefully remove the Trimmer from the Peg.

  • Page 15: Turning The Unit Off

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Turning The Unit Off (Refer to Figure #3D) There are two ways to turn the drive unit OFF: One is to push up on the switch Slider.

  • Page 16: Fault Detection And Correction/Wiring Diagram

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Fault Detection And Correction/Wiring Diagram Problem Probable Cause Remedy Check power plug. No input power. Check input power. Check power at switch Power switch failure.
  • Page 17 ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 Fault Detection And Correction/Wiring Diagram (Continued) HANGER SWITCH WIRING DIAGRAM Page 13...
  • Page 18 ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 THIS PAGE INTENTIONALLY LEFT BLANK Page 14...

  • Page 19: Maintenance

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 SECTION 7 .0 M aintenance W A R N I N G DISCONNECT POWER BEFORE SERVICING OR DISASSEMBLING. The Drive Unit has been designed in four main sub-assemblies :...

  • Page 20: Hanger Assembly

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 7 .2 Hanger Assem bly ( Ref er t o Han ger Par t s Li st Sect i on 9 .3 ) Remove the controller assembly as described in Section 7.1 Remove the two striker plate screws and remove the striker plate, peg, guard assembly, cover plate, actuator, spring, and slider.

  • Page 21: Enclosure/Frame/Motor Assembly

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 7 .4 Enclosure/ Fr am e/ M otor Assem bly ( Ref er t o Dr i v e Un i t Par t s Li st Sect i on 9 .1 )

  • Page 22: Spare Parts List

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 SECTION 9 .0 Spar e Par ts List 9 .1 Dr ive Unit Assem bly Page 18...
  • Page 23 ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 9 .1 Dr ive Unit Assem bly ( Continued) PART QTY. ITEM DESCRIPTION NUMBER USED COMPLETE DRIVE UNIT 115V/1/60Hz 173271 COMPLETE DRIVE UNIT 230V/1/50-60 Hz...

  • Page 24: Controller Sub-Assembly

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 9 .2 Contr ol Panel Sub-Assem bly Capacitor to be mounted with wire cap on top (Motor Cable) (Switch Harness) Page 20...
  • Page 25 ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 9 .2 Contr ol Panel Sub-Assem bly ( Continued) PART QTY. ITEM DESCRIPTION NUMBER USED CONTROL PANEL ASSY COMPLETE 115V/1/60Hz 173281 CONTROL PANEL ASSY COMPLETE 230V/1/50-60 Hz...

  • Page 26: Hanger Sub-Assembly

    ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 9 .3 Hanger Sub-Assem bly Page 22...
  • Page 27 ® OPERATING BETTCHER WHIZARD Ultra Drive High Speed Motor INSTRUCTIONS INDUSTRIES, INC. Rev. April 17, 2015 9 .3 Hanger Sub-Assem bly ( Continued) PART QTY. ITEM DESCRIPTION NUMBER USED Hanger Housing 163652 Flat Washer 120281 Lock Washer 120204 Screw 120787...

  • Page 28: About These Operating Instructions

    1 0 .1 Other Languages Translations into any of the languages used in the European Union are available at cost price upon request. Call or write the local Distributor or contact Bettcher Industries. 1 0 .2 Docum ent Identification Copies of this Operating Instruction may be ordered by quoting the Document ID as...

  • Page 29: Contact Addresses And Phone

    +1-440-965-4422 Fax: +41 41 348 02 29 Fax: +1-440-328-4535 Brazil Bettcher do Brasil Comércio de Máquinas Ltda. Av. Fagundes Filho, 145 Cj 101/102 – São Judas São Paulo – SP CEP 04304-010 BRASIL Tel: +55 11 4083 2516 Fax: +55 11 4083 2515...
