Summary of Contents for GRABBER GTT150HD
- Page 1 OPERATIONAL MANUAL Li-ion Gas Tool CONCRETE GAS TOOL...
- Page 2 C. Battery Light Indicator 1 - OPERATIONS A. Charging Battery Level All LEDs 100% Steps: 1. Plug the battery charger into the proper AC voltage source, green 1 Green and 1 Red LED light will be flashing. 1 Red LED 2.
- Page 3 E. Installing/Removing fuel cell G. Driving the pins Caution ! • Make sure the trigger is not held while inserting fuel cell. Caution ! • Empty fasteners in the magazine before installing fuel cell. • Please READ and UNDERSTAND the section “General Safety •...
- Page 4 1. Remove the pins, fuel cell and battery attached on the tool. 2. Adjust the knob clockwise to increase the driving depth, or vice versa. Grabber Construction Products gas tool allows user to perform regular maintenance easily. It helps maximizing the performance and durability of the tool.
- Page 5 SYMPTOM 3 2 - TROUBLESHOOTING Orange LED on charger is blinking. Possible reasons Services WARNING: To reduce the risk of serious personal injury, Charger damaged. Replace Charger. ALWAYS unload the battery, the pins and fuel cell from the tool before all repairs. B.
- Page 6 SYMPTOM 3 C. Pre-Combustion/Combustion Stage of Tool will not cycle - fan runs. Operation Possible reasons Services SYMPTOM 1 Contact Arm does not depress fully, tool does not operate. Fuel Cell is empty. Replace Fuel Cell. Possible reasons Services Contact authorized serviceman Spark does not occur.
- Page 7 SYMPTOM 2 Tool operates, but no fastener is driven. E. Returning/Purging Stage of Operation Services Possible reasons SYMPTOM 1 Fastener strip may be Use only fasteners meeting Tool operated and drove fastener, but piston did not return to up binding. designated specifications.
- Page 8 This operating manual has been drawn up with the greatest care. your country. Nevertheless, Grabber Construction Products assumes no liability for possible errors in this operating manual and their consequences. Furthermore, no liability is assumed for direct or consequential damages resulting from the improper use of the tool.
