Model GPCD-R
• Jump starts vehicles up to 4.0L V8
• Charges USB devices
• LED worklight with SOS strobe functions
• For use on 12VDC systems only
Read this manual before using this product. Failure
to do so can result in serious injury
For patent information visit www.geniecompany.com/patents
40639503993. ENG
400A Lithium Ion
Jump Starter
WARNING
!
SAVE THIS MANUAL
06/2019
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Genie ReliaVolt GPCD-R
Summary of Contents for Genie ReliaVolt GPCD-R
- Page 1 400A Lithium Ion Jump Starter Model GPCD-R • Jump starts vehicles up to 4.0L V8 • Charges USB devices • LED worklight with SOS strobe functions • For use on 12VDC systems only WARNING Read this manual before using this product. Failure to do so can result in serious injury SAVE THIS MANUAL For patent information visit www.geniecompany.com/patents...
- Page 2 Indicates a hazardous situation which, if not avoided, CAUTION could result in minor injury or death. NOTICE Addresses practices not related to personal injury. CAUTION STOP DO NOT return product to store Contact The Genie Company for Technical Assistance 1-800-354-3643...
- Page 3 Features Genie ReliaVolt™ Features: • Jump start most vehicle gas and diesel engines up to 8 cylinders under 4.0L. • System will initiate safeguards (power deployment prevention) and give a flashing light to indicate reverse polarity if the jumper cables are connected incorrectly.
- Page 4 • Do not put fingers or hands into the product. • Use of an attachment not recommended or sold by The Genie Company may result in a risk of fire, electric shock, or injury to persons. • To reduce the risk of damage to the electric plug or cord, pull the plug rather than the cord when disconnecting the unit.
- Page 5 • Do not operate Genie ReliaVolt™ in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. The Genie ReliaVolt™ can create sparks which may ignite the dust or fumes. • Keep children and bystanders away while operating the Genie ReliaVolt™.
- Page 6 Important Safety Instructions WARNING PERSONAL SAFETY • Consider having someone close enough by to come to your aid when you work near a lead-acid battery. • Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes. • Wear complete eye protection and clothing protection.
- Page 7 Important Safety Information WARNING • When charging the internal battery, work in a well- ventilated area and do not restrict ventilation in any way. • Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water.
- Page 8 Operating Instructions/Overview Genie ReliaVolt™ 12V Portable Power Unit USB Connector(s) Jumper Cable 115VAC Genie ReliaVolt™ 12VDC Genie Wall Charger ReliaVolt™ Car Charger...
- Page 9 Operation Instructions/Overview Jump Power Start Button Button USB Ports Jumper Unit Cable Charging Port Port Worklight Button LED Worklight/ SOS Strobe Fully charge Genie ReliaVolt™ prior to use. WARNING: Charge on a non-flammable surface.
- Page 10 1. Open USB port cover to find input charging port. 2. Plug in wall charger to a wall outlet -OR- plug in the car charger to the available 12V socket in the car, then plug into Genie Relia- Volt™ input port.
- Page 11 • DO NOT disassemble the Power Pack. Incorrect reassembly can result in risk of fire, electric shock. • Clean Genie ReliaVolt™ with a damp cloth. DO NOT use solvents or abrasives to clean unit. • DO NOT submerse the Genie ReliaVolt™ in water.
- Page 12 Try this process up to two additional times with at least 10 seconds in between attempts. If vehicle fails to start after 3 attempts, discontinue use of the Genie ReliaVolt™ and seek other methods to start vehicle.
- Page 13 OFF. 10. Remove BLACK NEGATIVE (-) jump starter clamp from vehicle battery post or chassis ground. 11. Remove RED POSITIVE (+) jump starter clamp from vehicle battery post. • Recharge Genie ReliaVolt™ as soon as possible to keep ready. • Store Genie ReliaVolt™ in its original case along with these instructions. BLACK (POS +) (NEG -)
- Page 14 Try this process up to two additional times with at least 10 seconds in between attempts. If vehicle fails to start after 3 attempts, discontinue use of the Genie ReliaVolt™ and seek other methods to start vehicle.
- Page 15 2. Plug included USB connector into port on unit. 3. Locate the correct USB plug adapter and plug into hand-held device. 4. Press POWER button on Genie ReliaVolt™. Charging will begin. 5. Once hand-held device is fully charged, press POWER button on Genie ReliaVolt™ and remove USB connectors.
- Page 16 Genie or not authorized by Genie to be used with the Device. For warranty claims or repair, please contact Genie Customer Service toll free at 1-800-354-3643 for further information. This warranty is made to the original purchaser of the Device only and is not transferable or assignable.
