EOS Saunadome Series Installation And Operating Manual

Sauna heating system

Advertisement

Quick Links

Saunadome
Installation and operating manual
GB
DruchNr. 29344138en
28.12
D
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Saunadome Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EOS Saunadome Series

  • Page 1 Saunadome Installation and operating manual DruchNr. 29344138en 28.12...
  • Page 2: Table Of Contents

    English Table of Contents Intended use ......................3 General notes ......................3 Important notes .......................4 Electrical connection ....................5 Technical data ......................6 Wiring diagram for sauna heaters ..............7 Detailed wiring diagram for sauna heaters ............7 Assembly ........................8 Minimum clearances ..................8 Electrical connection ..................8 Sauna stones ....................9 Maintenance and care ..................10 Service Address: ....................11...
  • Page 3: Intended Use

    Dear Customer, For installation and electrical connection of the rocker switch follow the installation in- You have purchased a high quality technical structions supplied with this part. system which will provide you with many ye- ars of enjoyable sauna bathing. This sauna General notes heating system was constructed in accor- dance with state-of-the-art European safety...
  • Page 4: Important Notes

    Important notes air intake and exhaust vents must not be closed. Please observe the information If assembled incorrectly, the sys- provided by your sauna cabin supplier. tem will present a fi re hazard. • For the adjustment and control of the sau- Please read this installation guide tho- na heating unit, one of the control units roughly.
  • Page 5: Electrical Connection

    in the table. Electrical connection • During the installation of the sauna hea- Your electrician will be able to accomplish ting unit, make certain that the vertical this work without further explanation in ac- cordance with the provided wiring schema- clearance between the upper edge of the tic and with the help of the circuit diagram sauna heating unit and the sauna ceiling...
  • Page 6: Technical Data

    Caution! When adding an infusion, please be aware that hot steam can also escape at the bot- Different heating reaction for sauna tom through the open mesh of the side parts. heater with a larger quantity of stones! Therefore please maintain a suffi cient clear- Please note that a considerable amount of ance! Danger of scalding!! energy is required to heat the large quantity...
  • Page 7: Wiring Diagram For Sauna Heaters

    Wiring diagram for sauna heaters 9 kW Sensor Saunasteuergerät control unit max. 9 kW N U V W L1 L2 L3 U V W WB WM N 400 V AC 3N 12-18 kW Sensor Saunasteuergerät ECON / EMOTEC control unit U V W N L1 L2 L3 N L1 L2 L3 N...
  • Page 8: Assembly

    Assembly Cabin ceiling Minimum clearances The sauna cabin interior must be at least 2.10 m in height. When assembling the sauna heater, make sure that the vertical clearance between the upper edge of the sauna heater and the sauna ceiling is at least 110 cm and the horizontal (side) clearance between the heater and cabin wall or other fl...
  • Page 9: Sauna Stones

    Right Sauna stones Sauna stones are a natural product. Always check the sauna stones at regular intervals. Sauna stones can be particularly attacked by strong infusion concentrations and will be corroded over the course of time. Please ask your sauna supplier. Thoroughly wash the supplied sauna stones under running water and insert them in the stone holder so that the heating rods can be...
  • Page 10: Maintenance And Care

    Maintenance and care DIN VDE part 703 must be observed for installation of the sauna heaters! All sauna heaters are made of a corrosion- This norm, in the latest version valid since resistant material. You should maintain and February 2006 with amendments to paragraph 703.412.05, makes the following statement;...
  • Page 11: Service Address

    Service Address: Outside of Germany please contact your EOS Saunatechnik GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible.
  • Page 12: Handling Procedures For Return Shipments (Rma) - Details For All Returns

    Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specifi ed below.This enabling us to ensure a quick and smooth handling of the return shipment.
