Summary of Contents for NuWhirl CozyHeat CMBC-298 Series
- Page 1 Installation & Operating Manual for Peel and Stick Models For use with CMBC-298 or CIHC-300 series ® Electronic Controllers NuWhirl Systems Corp | www.nuwhirl.com | 951-817-5600 MANHS REV C 5/9/2018 Page 1...
-
Page 2: Important Safety Instructions
Definitions WARNING May cause serious injuries or death May cause property damage CAUTION For information on NuWhirl Instructions, see: www.nuwhirl.com/docs/product-instructions.html When installing and using this electrical equipment, basic safety precautions should always be followed, including: Keep dry. Replace control if... - Page 3 Installation & Operating Instruction Manual TABLE OF CONTENTS Pre-Installation Preparation………………...……...…..……… P.4 Installation Procedure……...……………...……...…..……… P.6 Operations…………….…...……………...……..…..……… P.10 All Pre-Installation and Installation Procedures are for use by Tub Manufacturers or Qualified Service Personnel ONLY. Page 3...
-
Page 4: Pre-Installation Preparation
1. Inspect Heating Equipment Thoroughly Damage from shipping or delivery must be reported to the carrier and NuWhirl immediately. Do not install damaged equipment. Surface Heaters are tested by the factory prior to shipment. Although extremely rare, factory defects may happen and are to be reported to NuWhirl before the equipment is installed. - Page 5 Installation & Operating Instruction Manual 4. Mark Installation Location for Surface Brushing Determine the appropriate location of the heater underneath the tub and mark location as necessary. Make sure the location will allow the heater to be laid flat without any folding or bending.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Before installing, follow the pre-installation instructions on Page 4 carefully. The following steps apply to the peel-and-stick models. 1. Release Adhesive. Remove the release paper from the back of the heater. Do not touch or handle the adhesive side of the heater. 2. - Page 7 Installation & Operating Instruction Manual Note Once the heater is affixed to the tub, removing or repositioning it will compromise the adhesive. If the heater needs to be repositioned after application, additional adhesive will be required for secure adherence. In this case: Apply 3M 90 Spray Adhesive to the existing adhesive (non-insulated side) and repeat steps 2 and 4.
- Page 8 INSTALLATION INSTRUCTIONS (Continued) 5. Connect Heater to Electronic Controller Connect the surface heater blanket power cords with the respective outlets located on the top of the CIMC-298 or CIHC-300 controller. 5A. CIHC-300 Standalone System Installation Option Multiple Surface Heaters Max 96 Watts Combined Heater Blanket Load Controller CIHC-300-01-01-01...
- Page 9 Installation & Operating Instruction Manual 5B. CMBC-298 Master Bath System Installation Option Multiple Surface Heaters Max 96 Watts Combined Master Bath Bath Pump Heater Blanket Load Controller CMBC-298-series To 120V 15 or 20A GFCI Protected Receptacle Microbubble Pump or Blower Keypad Options CIDU-252-03-01-01 CIDU-252-03-03-03...
- Page 10 OPERATING INSTRUCTIONS It is recommended to turn CozyHeat on approximately 5-10 minutes prior to entering the tub. Press the Heater Button on the keypad to power on the surface heater. The Heater will warm the surface of the seat and/or back wall. The temperature will increase to a comfortable level within a 5-10 minute period.
-
Page 11: Retain This Manual For Future Reference
Installation & Operating Instruction Manual RETAIN THIS MANUAL FOR FUTURE REFERENCE For your records and future reference please fill in data below: Manufacturer: Model: Serial: Date of Installation: Page 11... - Page 12 NuWhirl Systems Corp | www.nuwhirl.com | 951-817-5600 MANHS REV C 5/9/2018 Page 12...
