Summary of Contents for Squareled VIGOR
-
Page 2: Color
Manual | VIGOR outdoor battery pack 1. Mechanical Specification... -
Page 3: Color
Unpacking Thank you for purchasing the VIGOR OUTDOOR BATTERY PACK. Every VIGOR OUTDOOR BATTERY PACK has been tested and shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your fixture for any damage and be sure all accessories necessary to operate the unit has arrived intact. -
Page 4: Color
Manual | VIGOR outdoor battery pack 3. Safety Information • Installation: Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of anchorage is stable before positioning the projector. The safety chain must be properly hooked onto the fitting and secured to the framework, so that,if the primary support system fails, the fitting falls as little as possible. -
Page 5: Color
Manual | VIGOR outdoor battery pack 4. Product Overview... -
Page 6: Color
Manual | VIGOR outdoor battery pack 5. Technic Data • Source: 12x 8W LED RGBW 4 in 1 • Led power: 96W • Optics: 30mm lenses standard beam 25 • Head adjustment: 0-120° • Cooling: Natural cooling by body • Control:... -
Page 7: Color
Manual | VIGOR outdoor battery pack 6. Operating Instructions... -
Page 8: Table Of Contents
Manual | VIGOR outdoor battery pack 7. DMX control mode 1 DMX Channel Channel Value Function Light off Color 1 Color 2 10-14 Color 3 …. …. 240-244 Color 48 245-249 Color 49 250-254 Color 50 Color 51 4 DMX Channel... - Page 9 Manual | VIGOR outdoor battery pack 8. Connection 8.1 DMX connection Connect all lights with controller,set all chanels are same. 8.2 Master slave connection Connect all lights with controller,set one light on , other all lights set it 8.3 Wireless connection If use diferenct DMX sender,should cancel the DMX signal record first.
-
Page 10: Auto
Manual | VIGOR outdoor battery pack Stat- This menu will let you select your desired static color mode and strobe mode 1. Tap the MENU button until “Stat” is displayed, press ENTER. 2. There will be five options. Press ENTER can select the option and press UP or DOWN button can select the value you desire as below. - Page 11 Manual | VIGOR outdoor battery pack Info - This will display the software version and working time 1. Tap the MENU button until “Info” is displayed. Press the ENTER button and the software vesion will be displayed. 2. Press the MENU button to leave this function.
- Page 12 Manual | VIGOR outdoor battery pack 9. Installation Because there is lithum battery inside - the light must be upwards,can‘t be downwards. 10. Flight case charge battery Open flight case,connect the inside power cable of flight case with light and then connect the outside power...
- Page 13 Manual | VIGOR outdoor battery pack 11. How to charge the battery 1. The battery life indicator located on the product displays the remaining amount of internal bat- tery life. Use the chart below to find out how much battery life remains per charge cycle.The light to the far right flashes during charging.
- Page 14 Manual | VIGOR outdoor battery pack 12. Service 12.1 Battery Manual 1. The energy of battery must be finished 100% when charge battery. 2. Should be charge one time each 3 month if do not use light.Must keep a few energy in battery,otherwise the volume of battery will be cut down 20%.
- Page 15 Manual | VIGOR outdoor battery pack Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
