- Page 1 Instruction Manual Sterno Hot Dog Cart Model No. 8080S 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2018 Gold Medal Products Co. Part No. 88914...
-
Page 2: Table Of Contents
Sterno Hot Dog Cart Model No. 8080S Table of Contents SAFETY PRECAUTIONS ..........................3 INSTALLATION INSTRUCTIONS ......................5 Inspection of Shipment ..............................5 Manual ....................................5 Model Description ................................5 Items Included with this Unit..........................5 Setup ....................................6 Steamer Pan and Lid Kit Options ...................... 8 OPERATING INSTRUCTIONS ........................ -
Page 3: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215... - Page 4 007_010914 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 5: Installation Instructions
Model Description The Sterno Hot Dog Cart is a stationary unit with four 4” legs, designed for use on a tabletop (the two wheels and push handles for display only). The unit is equipped with a handle on each end of the cart for transport (DO NOT transport unit while water is hot). -
Page 6: Setup
Sterno Hot Dog Cart Model No. 8080S Setup This unit has been tested at the factory. 1. Remove all packing material and tape before starting operation. 2. After unpacking the unit, rotate the display handles from the shipping position to the display (UP) position. - Page 7 Sterno Hot Dog Cart Model No. 8080S 6. To open the umbrella for use, pull down on the umbrella guide and twist slightly. As the umbrella is released, it will open (reference image shown). Umbrella Guide (pull down on guide to close)
-
Page 8: Steamer Pan And Lid Kit Options
Sterno Hot Dog Cart Model No. 8080S Steamer Pan and Lid Kit Options Reference Pan and Lid Kit options shown below (all kits available for purchase separately). Option 1 (Item No. 8080-01) Option 2 (Item No. 8080-02) (1) 1/2 x 6 Pan, Dome Lid w/Handle... -
Page 9: Operating Instructions
Sterno Hot Dog Cart Model No. 8080S OPERATING INSTRUCTIONS Operating Instructions Sterno Support This unit uses Sterno to heat the unit, follow all instructions and review all warnings on product prior to use. 1. Remove steamer pans/lids. 2. Pour distilled water into the bottom of the heating compartment – to a height of approximately 3/4”... -
Page 10: Care And Cleaning
5. Wipe the stainless steel parts with a clean cloth and cleaner designed for stainless steel, such as Gold Medal Watchdog Stainless Cleaner (Item No. 2088). DO NOT use oven cleaners or abrasive materials as they will damage parts of the machine. -
Page 11: Maintenance Instructions
Sterno Hot Dog Cart Model No. 8080S MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. -
Page 12: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... -
Page 13: Cabinet Exterior - Parts Breakdown
Sterno Hot Dog Cart Model No. 8080S Cabinet Exterior – Parts Breakdown 7, 8 9, 10 11 12, 13 Fasteners for Sterno Support Part Number Item Part Description 8080S HANDLEGRIP FOR 1"OD BLACK 88547 HANDLE TUBE 1" O.D. 88546 1/4-20 X 1 1/2 THUMB SCR... -
Page 14: Pan And Lid Kit Options - Parts Breakdown
Sterno Hot Dog Cart Model No. 8080S Pan and Lid Kit Options – Parts Breakdown Model 8080-02 Model 8080-01 Model 8080-04 Model 8080-03 Model 8080-05 gmpopcorn.com Page 14... -
Page 15: Umbrella Parts And Unit Accessories
Sterno Hot Dog Cart Model No. 8080S Pan and Lid Kit Options – Parts List Part Number Item Part Description 8080-01 8080-02 8080-03 8080-04 8080-05 1/2 X 6 STEAM PAN 39746 39746 STEAMER PAN CROSSBAR (support channel) 88565 1/4 X 6 STEAM PAN... -
Page 16: Warranty
© 2018 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
