Summary of Contents for Akron 9161
- Page 2 SHUTOFF DISASSEMBLY: 1. Place shutoff in vice with inlet pointing to the ground. 2. Remove cap (10) from back of shutoff using a 32mm socket wrench or adjustable wrench. 3. Remove spring (11) and set spring and cap aside. 4. Remove the two shoulder screws (1) from the handle using a 3/32” allen wrench 5.
- Page 3 Akron Brass for the appropriate technical service bulletin or return the O-Ring (2) 757274 shutoff to our factory: Akron Brass Co., Old Mansfield Rd., Wooster, Ohio 44691 or Akron Manufacturing Co., P.O. Box 280, Aylmer, Ontario N5H O-Ring (3) 757275 2R9.
- Page 4 Item No. 12 Item No. 24 O-Ring O-Ring 757274 757064 Item No. 14 Item No. 8 O-Ring Gasket 757275 717047...
