Installation Instructions for Web Slide Exercise Rail
Single Rail - Dry Wall with Wood or Metal Studs
TOOLS REQUIRED
Electric drill, 1/8" twist drill bit and a level.
Important: These instructions are specific to mounting on wood or steel
studs. Exercise Rails must be mounted to a wood or steel stud.
If you are mounting in concrete or block please
refer to the instructions specific to concrete/block on reverse.
Exercise Rails
1) Locate the center of the wood or steel stud.
2) Position Rail in desired location on the upright stud. If mounting multiple rails
begin with the bottom rail at floor level or just above the baseboard. See
mounting options on the reverse side of the Package Contents sheet.
a. Using level adjust the Rail until it is plumb.
b. Mark the wall with a pencil using the mounting holes of the Rail as guides.
3) Pre-drill marked holes 1/8" by 1" deep.
4) Attach Rail to wall with the 3" screws provided (B). Do not over torque. HAND
TIGHTEN each screw until head of screw rests snugly against unit.
5) Apply rail slot number labels (D) next to each slot in rail. Peel off backing and
stick. (Included with each rail section)
6) SAFETY SLIDE - Store Safety Slide in round holes on left side of rail. One
Safety Slide per rail (A)
• IF MOUNTING IN AN ENVIRONMENT SUBJECT TO MOISTURE CALL
800.544.7257 FOR PROPER MOUNTING HARDWARE.
• DO NOT INSTALL IN A POOL AREA
• IF ANY OF THE SCREWS ARE OVER TORQUED AND STRIPPED, THE
UNIT CANNOT BE SAFELY USED
• DO NOT USE IF ANY OF THE SAFETY SLIDES ARE MISSING. CALL
FOR REPLACEMENTS
• PRIOR TO EVERY EXERCISE SESSION, CHECK TO MAKE SURE THE
SCREWS ARE SECURELY FASTENED TO THE WALL & SHOW NO
SIGNS OF CORROSION.
(Do not mount in or around pool area.)
