Phone: 417.347.7431
Fax: 417.374.7442
service@gosciencecrazy.com
1747 North Deffer Drive
Nixa, Missouri 65714
Warning:
• Not a toy; use only
in a laboratory or
educational setting.
• California Proposition
65 Warning: This product
may contain chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
1. Port for Photogate 1
2. Display
3. Port for Photogate 2
4. Mode Button
5. Set Distance Button
1
2
4
5
6
Timer with Photogates
#TMRPG-1
Accurate timers are essential in the lab. This timer uses photogates
to measure the time it takes for an object to pass through the gates,
the object's speed, and the object's acceleration. It can store up to 10
sets of results. Just set the distance between your photogates and start
experimenting!
Parts and Buttons
6. Store Memory Button
7. Result Button
8. Reset Button
9. Power Switch
10. Fuse Box
3
7
8
Introduction
11. Port for Power Cord
12. Power Cord
13. Two Photogates
1
9
11
10
12
13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GSC TMRPG-1
Summary of Contents for GSC TMRPG-1
- Page 1 Phone: 417.347.7431 Fax: 417.374.7442 service@gosciencecrazy.com 1747 North Deffer Drive Nixa, Missouri 65714 Timer with Photogates #TMRPG-1 Introduction Warning: Accurate timers are essential in the lab. This timer uses photogates • Not a toy; use only in a laboratory or to measure the time it takes for an object to pass through the gates, educational setting.
- Page 2 How to Use 1. Plug your photogates and power cord into the timer. Flip its power switch to the ON position. 2. Press MODE once. From here you will be able to set the distance between your photogates. Using 100mm increments, you can choose distances anywhere from 100mm to 9900mm.
