PULSE 62V POLE SAW
DR
SAFETY & OPERATING INSTRUCTIONS
Serial No.
Order No.
Read and understand this manual and all instructions before operating the DR PULSE 62V POLE SAW.
DR Power Equipment
Toll-free phone: 1-800-DR-OWNER (376-9637)
Fax: 1-802-877-1213
Website: www.DRpower.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PULSE 62V POLE SAW and is the answer not in the manual?

Questions and answers

Summary of Contents for DR PULSE 62V POLE SAW

  • Page 1 ® PULSE 62V POLE SAW SAFETY & OPERATING INSTRUCTIONS DR Power Equipment Serial No. Toll-free phone: 1-800-DR-OWNER (376-9637) Fax: 1-802-877-1213 Order No. Website: www.DRpower.com Read and understand this manual and all instructions before operating the DR PULSE 62V POLE SAW.
  • Page 2 ® PULSE 62V POLE SAW...

  • Page 3: Table Of Contents

    DR Power Equipment reserves the right to discontinue, change, and improve its products at any time without notice or obligation to the purchaser. The descriptions and specifications contained in this manual were in effect at printing. Equipment described within this manual may be optional.

  • Page 4: Chapter 1: General Safety Rules

    Labels Your DR PULSE 62V POLE SAW carries prominent labels as reminders for its proper and safe use. Shown below are copies of all the Safety and Information labels that appear on the equipment. Take a moment to study them and make a note of their location on your Pole Saw as you set up and before you operate the unit.
  • Page 5 This Saw can sever body parts! Keep hands and feet away from the Chain and always keep both hands on the Pole.  Do not use your DR Pulse 62V Pole Saw for any job other than the intended use. ...
  • Page 6  Use only the DR Lithium Charger with DR Lithium Battery Packs. Do not use the DR Lithium Charger with Battery Packs from other manufacturers or other DR products. Use of a different Charger may cause a fire or explosion.

  • Page 7: Chapter 2: Setting Up The Dr Pulse 62V Pole Saw

    Chapter 2: Setting up the DR PULSE 62V POLE SAW DR PULSE 62V POLE SAW Controls and Features: Lock-Off Button Motor Section Trigger 62 Volt Lithium ON/OFF Battery Pack Switch Section Locking Knob Handle Section Oil Tank Sprocket Tip Chain...
  • Page 8 Output: Auto Sensing 62VDC 2.5A Charge Time 60 Minutes Carton Contents:  body (Handle, Motor and Extension section) DR PULSE 62V POLE SAW  Shoulder Strap  Bar, Chain and Sprocket Cover  Battery Pack and Charger Compare the Carton contents with the “Carton Contents” list above. If you have any questions, please contact us at www.DRpower.com.
  • Page 9 Charge the Battery Pack before your first use The DR PULSE 62V Pole Saw uses a sealed, Lithium-Ion Battery Pack. You MUST charge the Battery Pack for at least 60 minutes before you use the Pole Saw for the first time. If you do not charge it before using the Pole Saw, the Battery Pack’s charging capacity may decrease.
  • Page 10 Remove the Oil Tank Cap and add #32 Bar & Chain Oil to the “MAX” level on the side of the Tank (Figure 10). Install the Cap when finished. Chain Tension Screw Figure 9 Oil Tank Cap Oil Tank Figure 10 ® PULSE 62V POLE SAW...
  • Page 11 Installing the Battery Pack Battery Latch Slide the Battery Pack into the Battery cradle on the Pole Saw Handle Battery section, aligning the ribs in the cradle with the slots in the Battery until it is latched into place (Figure 11). Check that the Battery is securely locked into place.

  • Page 12: Chapter 3: Operating Your Dr Pulse 62V Pole Saw

    Starting and Stopping the Pole Saw Your DR PULSE 62V POLE SAW is equipped with an Automatic Oil Pump for Bar and Chain oiling. Before starting the Pole Saw, ensure the Oil Reservoir is full (see previous page). Refill when the oil level drops to the minimum level Mark.
  • Page 13 Proper Cutting Stance  Balance your weight with both feet on solid ground (Figure 15).  Your body should always be to the left of the Chain Line.  The most typical cutting application is to position the unit at an angle of 60°or less depending on the specific situation.
  • Page 14 The Battery can be used to charge/operate phones or other electronic devices USB Port that use a USB cord. 1. Remove the Battery from the Pole Saw. 2. Plug the device into the USB Port of the Battery (Figure 19). Figure 19 ® PULSE 62V POLE SAW...

  • Page 15: Chapter 4: Maintaining Your Dr Pulse 62V Pole Saw

    Chapter 4: Maintaining Your DR PULSE 62V POLE SAW Always remove the Battery Pack before performing any maintenance, or repairs to your Pole Saw. Chain Tension Properly Adjusted Warm Chain Check the Chain Tension before using the Saw when the Chain is cold. The correct tension of a cold Chain is when there is no slack on the underside of the Bar, the Chain is snug, but you can turn it by hand without binding.
  • Page 16 Correct 30 degrees – File holders are marked with guide marks to align file properly to produce top plate angle. -Less than 30 degrees – for cross cutting. -More than 30 degrees – feathered edge dulls quickly. ® PULSE 62V POLE SAW...
  • Page 17 Tools and Supplies Needed:  File Holder  5/32" Round Chain File  Wire Brush  Depth Gauge jointer  Flat File  Safety Glasses  Gloves Figure 26 Note: Occasionally remove filing from the file with a wire brush. Position the File into a left-hand cutter with the holder and file at a 30°...
  • Page 18 ® ® Use only the DR 62V Charger with DR 62V Battery Packs. Do not try to use the DR 62V Charger with Battery Packs from other manufacturers.  Make sure the Charger Power Supply is plugged into a normal household voltage, 120volts, 60Hz, AC only.
  • Page 19 Battery LED Lights (Figure 31) Indicator Button You can check the charge percentage of your 62V Battery by pushing the Indicator Button on the front of the Battery. The number of Green LED indicators will tell you the % of power left in the Battery. 1-25%, 2-50%, 3-75% and 4-100%.

  • Page 20: Chapter 5: Troubleshooting Your Dr Pulse 62V Pole Saw

    Most problems are easy to fix. Consult the Troubleshooting Table for common problems and their solutions. If you continue to experience problems or need repairs beyond these minor adjustments, visit our website at www.DRpower.com or call DR Power Equipment. Toll Free at: 1-800-DR-OWNER (376-9637) for assistance.

  • Page 21: Notes:chapter 6: Parts Lists And Schematic Diagrams

    Notes: CONTACT US AT www.DRpower.com...
  • Page 22 Chapter 6: Parts Lists and Schematic Diagrams Parts List – PULSE 62V POLE SAW Note: Part numbers listed are available through DR Power Equipment. Not all parts appear on all diagrams. Ref# Part# Description Ref# Part# Description A0000222200 Chain, Oregon, 10"...
  • Page 23 Schematic – PULSE 62V POLE SAW contact us at www.DRpower.com...
  • Page 24 If you drop the Saw, carefully inspect it for damage. If the Battery is damaged, Bar is bent, Housing cracked, or Handle broken or if you see any other condition that may affect the Saw's operation, visit our website at www.DRpower.com or call DR Power Equipment Toll Free at: 1-800-DR-OWNER (376-9637) for assistance before putting it back into use.
