Kee safety Kee Guard Installation Instructions

Kee Klamp Components
®
The Kee Klamp safety components below are the most commonly
employed in KeeGuard fall protection systems.
15-8 14-8 BC53-88
74-7 26-7
Anatomy of the Setup
26-7
74-7
440-7
Kee Guard Components
®
1 1/2 "
Uprights are
Pipe
adjustable
from
0° to 11°
42"
OSHA Compliant
The Kee Klamp safety components, and specially designed KeeGuard
safety components, when used to construct the KeeGuard railing system,
61-8
using a 42'' high guard railing, will meet or exceed the requirements of the
OSHA Safety Standard of a single 200 lb. load applied at any location and
in any direction along the top of the rail when the correct specification of
pipe is used and the correct method of design is employed. The integrity
of the structure to which the system may be fixed and the fixings used
133D will need to be inspected to ensure that they are capable of meeting the
imposed load requirements.
Fall Protection
74-7
74-7
135-8
An open style crossover
component allows
for fast installation of
horizontal rails.
Toe Board
Toe board option when
required is available.
Kee Klamp, Kee Lite, Kee Stainless, KeeGuard, Kee Dome, Kee Hatch, Kee Mark, Kee
Access, KwikKit, Beam Clamp, and Box Bolt are all registered trademarks of Kee Safety, Inc.
While every effort has been made to ensure the accuracy of the information contained in
this brochure, Kee Safety, Inc cannot be held responsible for any errors or omissions. Kee
Safety, Inc. reserves the right to alter or withdraw products without prior notice. Kee Safety,
Inc accepts no responsibility for any loss or damage arising from improper use of their
products. Copyright 2019 Kee Safety, Inc. All Rights Reserved.
Portable, Deadweight
Anchor Systems that do
not penetrate the roof
Anchor
membrane
Safety Barrier System
for safe passage through
hatches in rooftops or floors
Skylight Guardrail System,
fits skylights, roof lights,
and dome lights with curbs
Skylight Screens for
curb style, standing seam,
and rib/corrugated metal
roof skylights
SKYLIGHT
SCREENS
USA Canada
Kee Safety, Inc. Kee Safety, Ltd.
100 Stradtman Street 219 Connie Crescent, Unit 9
Buffalo, NY 14206 Concord, Ontario L4K 1L4
Tel: (716) 896 4949
Tel: (905) 669 1494
Fax: (716) 896 5696 Fax: (905) 669 4347
Toll Free: (800) 851 5181 Toll Free: (877) 505 5003
www.keesafety.com www.keesafety.ca
Email: info@keesafety.com
KS/KGI_US_V1/0110
S A F E T Y A T T H E H I G H E S T L E V E L
Installation Instructions
•
NO PENETRATION OF THE ROOF MEMBRANE
•
INDEPENDENTLY TESTED, MEETS OR EXCEEDS
SAFETY STANDARDS
•
NO WELDING, BENDING, OR THREADING OF PIPE
CSI 077200
January 2019
Independently tested to
OSHA Standard 29 CFR 1910.23
Ontario OHS Act
Meets ANSI Standards
