- Page 1 Electrify America Level 2 Charger OPERATING INSTRUCTIONS...
- Page 2 INSTRUCTIONS FOR USE...
-
Page 3: Table Of Contents
This document might not contain the latest changes to the product’s specifications or processes described herein. In case of questions or problems with this product please call Electrify America Customer Assistance: Visit www.electrifyamerica.com/charging-at-home 1-833-532-2778 for the most up to date information. - Page 4 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS DANGER Risk of fatal injury Warning of electrical voltage! This symbol in conjuction with the key word DANGER indicates an imminent danger. It will cause death or severe injuries if not avoided. WARNING Personal injury This symbol in conjuction with the key word WARNING indicates a possibly hazardous situation.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING When using electric products, always follow basic precautions, READ ALL THE INSTRUCTIONS BEFORE INSTALLING, OPERATING, including the following: MAINTAINING, OR USING THIS PRODUCT. SAVE THESE INSTRUCTIONS. THEY MUST BE PROVIDED TO EACH NEW OWNER. About this document Intended purpose This device is intended exclusively for...
- Page 6 • Electrify America is not responsible for flammable vapors, the vapors could ignite, creating an explosion. Store hazardous physical injury, damage to property or...
- Page 7 IMPORTANT SAFETY INSTRUCTIONS DANGER WARNING WARNING CAUTION Handling live components This equipment is intended only If the electricity service To reduce the risk of fire, incorrectly may cause for charging vehicles that do to the charger is damaged, connect only to a circuit grievous injuries or death.
- Page 8 IMPORTANT SAFETY INSTRUCTIONS EMC compliance statement: FCC Part 15 Note: This equipment has been tested and This device complies with part 15 of the DANGER found to comply with the limits for a Class B FCC rules. Operation is subject to the Radiofrequency digital device, pursuant to Part 15 of the FCC following two conditions:...
-
Page 9: Product Overview
Check that the warranty seal on the back of the charger is intact. Do not operate the product unless the warranty seal is undamaged. Damaged warranty seals void the warranty. If warranty seal is broken contact Electrify America at 1-833-532-2778 (24 hours / 7 days) -
Page 10: Clicking The Charger
CLICKING THE CHARGER INTO THE DOCK Clicking the charger into the Dock Before mounting the charger, make sure the power supply to the Dock is off. See the Installation Instructions provided with the Dock for complete installation details. 90° Take the charger and identify Connect the black ribbon data LAN 1 RJ45 (charger communication) the connecting points (Shown... - Page 11 CLICKING THE CHARGER INTO THE DOCK CAUTION CAUTION Ensure that the flat ribbon The set screws should only be data cables are not trapped fully inserted when the locking between the Dock and charger clip is fully inserted. when mounting the charger. Place the charger carefully on Keep a firm hold on the charger If necessary, readjust the locking...
-
Page 12: Charging
CHARGING Charging Charging involves connecting your vehicle to the charger, authenticating the charging process, charging your vehicle, and finally disconnecting your vehicle from the charger. Please make sure that the connected cable is hung carefully back up. Connect your electric vehicle Plug into the vehicle, the LED Charging is complete when both to the charger. -
Page 13: Troubleshooting
Follow instructions in the app or contact • Charging connector not plugged in correctly sunlight to reduce the risk of overheating. Electrify America Customer Assistance at If a malfunction persists, restart the charger • There is a charging problem at the vehicle: 1-833-532-2778 (24 hours / 7 days). - Page 14 Dock from the wall outlet. If your Dock is hardwired to the main power supply, switch off the circuit breaker. If the fault persists after the charger has cooled down and been restarted, then contact Electrify America Customer Assistance at 1-833-532-2778 (24 hours / 7 days).
- Page 15 MOVING AND STORAGE INSTRUCTIONS MOVING AND STORAGE INSTRUCTIONS Do not lift or carry the charger by the flexible When stored, make sure that the connector cord. Do not allow the connector cable to drag cable does not cause any obstruction and or touch the ground when moving the charger.
-
Page 16: Specifications
SPECIFICATIONS Specifications With cable Dimensions Measurements H x W x D (without Dock) 17 3/4“ x 7“ x 5“ (450 mm x 180 mm x 126 mm) Cable length 24‘-7“ (7.5 m) Installation type Wall, pole Weight (without Dock) 14.1 lbs (6.4 kg) Environment Enclosure rating Type 3S... - Page 17 SPECIFICATIONS Specifications With cable Authentication / activation Authentication-free charging Pilot signal (IEC 61851-1:2017) Plug&Charge ISO 15118 ready Card activation Remote activation Vehicle communication Pilot signal (IEC 61851-1:2017) Certifications UL / FCC certificate (tested and confirmed by a certified body)
-
Page 18: Notes
3. This product is designed for use with The charger may only be cleaned with water; the use of lukewarm water is recommended. Level 2-compatible electric vehicles. Do not use cleaning agents containing solvents. 4. The product can be installed and used in indoor and outdoor areas. -
Page 19: Legal Notice
