Camera Mounting Instructions
Step 1:
Place the mount at the desired location, assuring
that location of the power cord thread is also at the
desired location. Use a pencil to mark the holes.
Step 2:
Using a 6 mm drill bit, drill two 25 mm deep holes
over the pencil marks. For a plaster, drywall, or
concrete wall, insert the plastic anchors to support
the screws first.
Step 3:
Place the mount over the holes that are in the wall.
Make sure to align the mount holes with the holes
in the wall. Use the supplied screws to attach the
mount to the surface of the wall.
Step 4:
Align the bottom of the camera to the threads on the
mount. Assure that the camera is securely snapped
into place.
1
2
3
4
