Summary of Contents for Everlea MUC1004
- Page 1 IP PBX Installation guide MUC1004/2008/2016 IP PBX Installation guide Version V1.0 Date: 20th July, 2016 1 / 20...
- Page 2 IP PBX Installation guide 2 / 20...
-
Page 3: Table Of Contents
IP PBX Installation guide Table of Contents Preparation before installation ....4 Hardware specifications ......4 2.1 overview ....................4 2.2 Specifications and Operating Environment ..........8 MUC Series IP-PBX Installation ..... 8 3.1 Placement Instructions ................. 8 3.2 Installation Instructions ................ 8 3.2.1 Connection of Ethernet Ports ............ -
Page 4: Preparation Before Installation
For the input of 100-240V AC power(only for MUC2008/2016) Phone line Network cable For wireless module (optional, according Antenna to the number of GSM/UMTS module) Table1-1 Packing List 2. Hardware specifications 2.1 overview Figure 2-1 Front view of MUC1004 4 / 20... - Page 5 IP PBX Installation guide Figure 2-2 Front view of MUC2008 Figure 2-3 Front view of MUC2016 Table 2-1 Description of Front view Index Indicators Description On: Starting Off: Abnormal Blinking every 0.5s: Normal status On: Power on Off: Power off Green LED: indicates the Internet interface is in Link.
- Page 6 FXO port is in a call. Alternately blinks Green and Red: FXS port is ringing. Alternately blinks Green fast: FXS port is in a call. Figure 2-4 Rear view of MUC1004 Figure 2-5 Rear view of MUC2008 6 / 20...
- Page 7 Hold RST button 8 seconds, RUN LED being ON during this time DC 12V Power connector of DC power. Input: DC12V 3A/DC12 1A(MUC1004 only) For the storage of call recording files MUC2008 provides two 10/100 adaptive RJ45 Ethernet ports, marked as LAN and WAN.
-
Page 8: Specifications And Operating Environment
IP PBX Installation guide 2.2 Specifications and Operating Environment Description 185*152*45mm(MUC1004);220*197*45mm(MUC2008); Size 323*197*45mm(MUC2016) Power supply MUC1004: AC100~240V,50/60Hz Input, DC 12V/1A Output MUC2008/2016: AC100~240V,50/60Hz Input, DC 12V/3.3A Output Operation 0~50℃ temperature Storage -20~80℃ temperature Operation 10%~90% Humidity 3. MUC Series IP-PBX Installation To avoid unexpected accident，personal injury or device damage，please read the... -
Page 9: Connection Of Ethernet Ports
IP PBX Installation guide We use the MUC2008 device as an installation case as follows: 3.2.1 Connection of Ethernet Ports All the MUC series IP-PBX provide two standard 10/100M adaptive RJ45 Ethernet port, LAN port and WAN port. WAN Port Connection Connection one end of the network cable to the WAN port of MUC series device, and the other end to Ethernet port of a hub, switch or ADSL modem. - Page 10 IP PBX Installation guide For instance, if the port 1 and port 2 are FXO port, the connection could be like as below: Figure 3-2 PSTN connection The other end of phone line connects to PSTN line or a FXS of traditional PBX. 2.
-
Page 11: Connection Of Fxs Ports
IP PBX Installation guide Figure 3-4 Install the Antenna 3. Connection of BRI port The BRI port could be connected to the BRI line or the BRI port of a traditional PBX with a BRI RJ45-RJ11 cable. 3.2.3 Connection of FXS Ports The FXS port could be connected to an analog phone or a fax with a phone line. -
Page 12: Power Connection
IP PBX Installation guide Figure 3-5 FXS Connection The other end of the phone line connects to an analog phone. 3.2.4 Power Connection After make sure the device has installed completed, connect the power cord. The MUC series adapt 12VDC Power adapter, make sure AC power supply grounded well to ensure the reliability and stability. - Page 13 IP PBX Installation guide Figure 3-5 Overall Flow chat There are some typical application of the MUC series IP-PBX. Figure 3-6 Application1 13 / 20...
- Page 14 IP PBX Installation guide Figure 3-7 Application2 Also, the MUC series can cooperate with the MWG series (VOIP GSM/UMTS Gateway) for more flexible and powerful wireless application. Figure 3-8 Application3 14 / 20...
-
Page 15: Muc Series Basic Configurations
IP PBX Installation guide 4. MUC series Basic Configurations 4.1 Factory Defaults The MUC series device provide web-based configuration interface for administrator and account user. The administrator can manage the device by log in the web interface. The factory default IP address: LAN: 192.168.6.200 Access path:http://[IP address] User name: admin... - Page 16 IP PBX Installation guide Figure 4-1 Web login interface NOTE: please check if the IP address that assigned to the network port (LAN or WAN) is in the same segment with the PC’s IP address. Via the web configuration interface, the admin can set all the system configuration, including Network Configuration、...
-
Page 17: Network Settings
IP PBX Installation guide Figure 4-2 Web Management System It is strongly recommended, change the default password to a new password for system security .Click “System Preferences”->”Password” on the web. Figure 4-3 Password Setting 4.3 Network Settings After logging in the web configuration interface, generally the first step is to configure the IP address. - Page 18 IP PBX Installation guide Figure 4-4 WAN Setting LAN settings Click “Network Configuration”->”LAN Configuration” on the navigation tree. LAN port is used for the interoperability of MUC2008.If LAN port is connected to the company’s LAN, please configure the correct IP address and corresponding subnet mask.
-
Page 19: Reset To Factory Defaults
8 seconds with a paper clip or a pencil tip. 5. Conclusion This Installation Guide only explains the installation and basic setting, for more detail about functionality and setting, please refer to the relative documents as below: “MUC1004_Datasheet_V1.0” “MUC1004 Administrator_guide_V1.0” “MUC2008_Datasheet_V1.0” “MUC2008 Administrator_guide_V1.0” 19 / 20... - Page 20 IP PBX Installation guide “MUC2016_Datasheet_V1.0” “MUC2016 Administrator_guide_V1.0” 20 / 20...
