SHENZHEN POLINOVEL TECHNOLOGY CO., LTD
V+ Solar Home Battery
(Lithium-Iron Phosphate Battery)
Product Manual
Version: 1.0
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD
Xintun Building 804, Xintun Middle Road 50, Longcheng Street,
Longgang District, Shenzhen, 518100, China
Tel: (86)755-28906569
Fax: (86)755-28903442
Email:
sales@plgenergy.com
Web:
www.top1battery.com
1
Advertisement
Table of Contents
Summary of Contents for Polinovel V+ Series
- Page 1 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD V+ Solar Home Battery (Lithium-Iron Phosphate Battery) Product Manual Version: 1.0 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Xintun Building 804, Xintun Middle Road 50, Longcheng Street, Longgang District, Shenzhen, 518100, China Tel: (86)755-28906569 Fax: (86)755-28903442 Email: sales@plgenergy.com...
- Page 2 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD LEGAL NOTICES Copyright of Shenzhen Polinovel Technology Co., Ltd. Enjoin from abstracted reproduced or translated by any unit or individual in any way without the written permission. Rights Reserved. This product confirms to environmental protection and personal security. Product storage, using and disposal should be in accordance with product manuals, relevant contract and national laws.
- Page 3 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Preface Thank you for using the Wall-Mounted Solar Home Battery from Shenzhen Polinovel Technology Co., Ltd. In order to bring you the best product at the best price under the safest conditions, we have been making progress all the time. Because of your concern, our efforts will be verified.
-
Page 4: Table Of Contents
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Contents 1 Safety Instructions ............................5 1.1 Symbol Description ..........................5 1.2 Precautions ............................... 5 2 Product Introduction ............................7 2.1 Product Description ..........................7 2.2 Product Features ............................. 8 2.3 Product Model ............................8 2.4 Battery Management System (BMS) ....................8 2.5 Charge Parameters ..........................10... -
Page 5: Safety Instructions
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Safety Instructions This chapter describes safety signs and safety precautions. Please read this chapter carefully before proceeding with any operation on this product to avoid personal safety or equipment damage due to unsafe operation. 1.1 Symbol Description The safety symbols referenced in this manual are shown in Figure 1.1-1. - Page 6 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Battery use precautions The Wall-Mounted Solar Home Battery is composed of a battery pack and a control system. Non-professionals and improper operation and use may cause serious consequences such as sparking and short circuit. The installation and maintenance of the system must be performed by professional technicians, and the use must strictly comply with the relevant safety regulations.
-
Page 7: Product Introduction
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Product Introduction 2.1 Product Description a. Polinovel wall-mounted solar home battery is an energy storage battery pack, which is used together with solar modules, solar inverters and power grid to form a residential energy storage system with off-grid function. -
Page 8: Product Features
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD 2.2 Product Features (1) Display for checking battery status and operation, including, a, battery SOC; b, battery voltage and current; C, battery charging and discharging status. Figure 2-1 (2) Battery management system and battery protection system. - Page 9 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD High Voltage Protection in Charge When charging, the protection will turn on if the battery or any single cell has high voltage, and the battery will stop charging. When battery voltage and all single cells voltage are back to normal, protection will be removed.
-
Page 10: Charge Parameters
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD The protection parameters of V+ solar home batteries please read table below. Table 2-2 Protection Parameters Parameter to Parameter to Item Type Protective Function Remove Protection Protection Cell Under-voltage in Discharging 2.5V 2.9V Cell Over-voltage in Charging 3.75V... -
Page 11: Installation
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Table 2-4 Discharging Parameters Voltage Range in Discharging Current Limit in Discharging Model V+3000 43.2V 57.6V 100A V+5000 43.2V 57.6V 100A V+7000 43.2V 57.6V 100A 2.7 Installation 1. Please read this manual carefully before installation. If the product is not installed... - Page 12 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD c, can not be mixed with flammable materials (such as packaging materials cartons, etc.), it is recommended to use a separate warehouse to store battery packs; d, there’s secondary fire doors in the warehouse; e. according to the instructions on the packaging of lithium battery and the stacking requirements, please do not stack more than a certain height;...
-
Page 13: Installation Instructions
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Installation Instructions 3.1 Installation requirements This part of the guide provides the installer with the choice of the appropriate installation location to avoid damage to the battery or the associated operator. A. The product can be installed on the wall or on the ground. -
Page 14: Battery Pack Appearance And Structure
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD 3.2 Battery pack appearance and structure Figure 3-1 3.3 Handling and Installation DANGER! The energy storage battery pack is heavy, pay attention to balance when handling, so as to prevent the battery from falling and hurting the operator. - Page 15 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Installation Steps (1) Install the wall mounting kits a. Mark the drilling position on the wall with the wall mounting kits; Figure 3-3 to Figure 3-5 show the outline of the battery pack and the shape of the wall mounting plate and the mounting hole size for all three models.
- Page 16 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Figure 3-4 ( Model V+5000)
- Page 17 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Figure 3-5 ( Model V+7000) b. Drill holes in the marked positions with a hammer drill, insert the plastic parts, meanwhile, drill the tapping screws; c. Install the wall mounting plate on the wall as shown in Figure 3-6 below; fix it with M8*50...
- Page 18 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Figure 3-6 (2) Lift the battery pack and hook it on the wall mounting plate through the hooks on the wall mounting plate, as shown in Figure 3-7. Figure 3-7...
-
Page 19: Panel And Switch Button Description
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD (4) Wire lug processing This battery pack comes with two pieces of wire lugs, but does not come with the external positive and negative wire harness. When the battery pack is installed, the wire lug should be processed with proper wires (4AWG wires)as shown in Figure 3-8 below. -
Page 20: Sleep Mode
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD a, Display: display battery system information b, Master switch: air switch, turn off and turn on the battery system c. Power / Reset: When the BMS is in sleep mode, press and hold this button for 1 second and release, the BMS is activated;... -
Page 21: Parallel Use
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD (3) Connect RS485 or RS232 communication, turn on the communication device. 3.6 Parallel Use Parallel use of this battery pack is allowed. Before the battery packs are connected in parallel, the following operations and checks must be performed. - Page 22 Do not connect the battery packs when they are charging or discharging. e. Do not mixing connect different capacity battery packs in parallel. f. Do not mixing connect the V+ battery packs with other models of batteries from Polinovel or other manufacturers.
-
Page 23: Troubleshooting
SHENZHEN POLINOVEL TECHNOLOGY CO., LTD 3.7 Troubleshooting Common Fault Analysis and Solutions as below. Item Fault Symptom Solution Remark 1. Check if the master switch If the battery pack can is turned on. be charged, it will work Press POWER 2. - Page 24 SHENZHEN POLINOVEL TECHNOLOGY CO., LTD Appendix: Models and specifications of Polinovel V+ solar home battery Item Model Solar Home Battery V+3000 V+5000 V+7000 Nominal Capacity 66Ah 99Ah 148.5Ah Nominal Voltage 51.2V 51.2V 51.2V Voltage Range 43.2-57.6V 43.2-57.6V 43.2-57.6V Continuous Charge &...
