DAS Compact/Classic. 2. USB Connector (new): To connect the R-DAS Tiny to the PC for downloading flight data, configuration and firmware upgrades. 3. Power/Igniter Connector (new): This is an 8-pin connector to supply processor and igniter power and 4 igniter outputs. For a detailed description see further.
Page 3
Buzzer The R-DAS Tiny has a buzzer with status signaling that is very similar to the R-DAS Compact and Classic. The only difference is the signal for igniter discontinuity. A discontinuity in any of the for igniters is now reported by two buzzes.
Page 4
4. Vign - Yellow Igniter supply 5. Drogue - Orange Drogue igniter Main igniter 6. Main - Red 7. Igniter 3 - Brown Igniter 3 8. Igniter 4 - Black Igniter 4 Pyro outputs Figure 2: Standard R-DAS Tiny wiring.
Page 5
8. Igniter 4 - Black Breakwire Pyro outputs Figure 3: R-DAS Tiny wiring with optional igniter power supply, breakwire, and un-used Pyro 3 output. Note: Earlier versions of the wiring loom had a white #1 wire color. LED’s There are four red LED’s on the R-DAS board. These LED’s are used to indicate continuity of the igniters.
