Summary of Contents for Kramer 103EQ
- Page 1 USER MANUAL MODEL: 103EQ 3 Band Parametric EQ P/N: 2900-300594 Rev 1 www.kramerAV.com...
-
Page 4: Table Of Contents
Figure 4: Connecting a Balanced 6.5mm Phone Jack Figure 5: Connecting an Unbalanced RCA Input Figure 6: Connecting an Unbalanced 6.5mm Phone Jack Figure 7: EQ Graph shape – Requirements Figure 8: Setting the 103EQ for using with the Galil-2C Speakers 103EQ – Contents... -
Page 5: Introduction
Congratulations on purchasing your Kramer 103EQ 3 Band Parametric EQ, which is ideal for the following typical applications: • Enhancing the sound of the Kramer Galil-2C Closed-Back Ceiling Speakers Note that the 103EQ needs to be set as described in Section 5.1 to be used with the Galil-2C. •... -
Page 6: Getting Started
Avoid interference from neighbouring electrical appliances that may adversely influence signal quality • Position your 103EQ away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 7: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling/. -
Page 8: Overview
Overview The Kramer 103EQ is a 3-band parametric equalizer that is used to optimize the quality of sound of speakers, specifically the Kramer Galil-2C. The 103EQ fixes microphone feedback and fine-tunes the room sound. The 103EQ lets you set the low, mid and high frequencies separately allowing flexibility in fitting the audio signal to your specific needs. -
Page 9: Defining The 103Eq 3 Band Parametric Eq
Defining the 103EQ 3 Band Parametric EQ This section defines the 103EQ. Figure 1: 103EQ 3 Band Parametric EQ Feature Function Hz Control Adjust to set between 40Hz and 1200Hz Band 1 Q Control Adjust to set the Q GAIN Control... -
Page 10: Connecting The 103Eq
Kramer 920 power amplifier). 3. Connect the 920 power amplifier to the audio acceptor (for example, the Kramer Galil-2C). 4. Connect the power adapter to the 103EQ and plug the power adapter into the mains power supply. 103EQ - Connecting the 103EQ... -
Page 11: Figure 2: Connecting The 103Eq 3 Band Parametric Eq
Figure 2: Connecting the 103EQ 3 Band Parametric EQ 103EQ – Connecting the 103EQ... -
Page 12: Connecting The Input And The Output
When using a balanced input source / output acceptor and connector, you must ensure that the hot, cold, and ground pins of the connector are matched up to the +, –, and ground pins of the 103EQ terminal block connector respectively. The following diagrams illustrate how to connect standard XLR and 6.5mm phone jack. -
Page 13: Figure 5: Connecting An Unbalanced Rca Input
The LINE OUT pinout is identical to the LINE IN pinout examples illustrated in Figure 5 Figure A jumper is required for connecting an unbalanced input/output. Figure 5: Connecting an Unbalanced RCA Input Figure 6: Connecting an Unbalanced 6.5mm Phone Jack 103EQ – Connecting the 103EQ... -
Page 14: Setting The 103Eq
Setting the 103EQ The 103EQ parametric equalizer lets you adjust the sound so it will suit your needs. For optimal adjustment of the 103EQ when using with the Kramer Galil-2C, see Section 5.1. When setting the 103EQ for other applications, bear in mind that: •... -
Page 15: Setting The 103Eq To Use With The Galil-2 Speakers
6. Take a moment to listen to the result. 7. Repeat this process as many times as necessary until you are happy with the resulting sound. Setting the 103EQ to use with the Galil-2 Speakers The following are the speaker equalizer requirements: Band 2... -
Page 16: Eq Graph Shape
Figure 7 defines the required EQ graph shape Figure 7: EQ Graph shape – Requirements To setup the 103EQ to work with the Kramer Galil-2C speakers, set the device as illustrated in Figure 8 (note that the gray horizontal line indicates the default setup). -
Page 17: Technical Specifications
Power supply (12V/2A) Options: RK-3T 19” rack adapter All Audio specification are from Analog In to Analog Out. Specifications are subject to change without notice For the most updated resolution list, go to our Web site at www.kramerav.com/ 103EQ – Technical Specifications... - Page 19 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
