Summary of Contents for Maidaid Halcyon Barista Compact
- Page 1 Barista Compact Espresso coffee machine Installation and user manual Maidaid Barista Compact Installation and user manual V1.0...
-
Page 2: Installation
Installation Overview 300mm Power Power Power (2nd Position Switch or plug) Cold Water (15mm) Waste Co ee Machine. if required. Grinder – 13 amp socket required. Counter. Power connection for co ee machine Under counter or under grinder (must be within 1 metre). Switch or plug. Knock-out drawer. -
Page 3: Preparing For Installation
Preparing for Installation Services and equipment required for installation Warning: Installation of this appliance must only be carried out by trained persons available. All services must be in place prior to installation. ALL CALLS TO UNPREPARED SITES MAYBE FULLY CHARGEABLE. Mains water: 15mm mains cold water supply with ¾'' BSP standard washing machine stop cock. - Page 4 Preparing the area for installation Note: The appliance must be installed in a location where it can be over seen by trained personnel and its use and maintenance is restricted to trained personnel. Plan view for drilling counter for Co ee Machine Area for Grinder 110mm Depth from the back of the machine to the hole.
-
Page 5: Installing The Coffee Machine
Installing the coffee machine Connecting the waste pipe of the machine and tighten with the wormdrive clip provided. Then feed the waste hose under the machine and down through the 2” hole already cut out. Pull taught and ensure no kinks are present in pipe. -
Page 6: Connecting The Water Supply
Connecting the water supply the water hose under the machine and down through the 2” hole already cut out. Connect this to a washing machine tap (Cold water supply) with ¾'' BSP male thread or to the water debris entering the machine. Note: It is highly recommended that the new hose sets supplied with the co ee machine are used. -
Page 7: Connecting The Power Supply
Connecting the power supply Run the mains cable through the hole in the bottom of the machine or underneath to the nearest power supply. Make sure your mains supply is within 1 metre of the machine and has easy access for power isolation. Single phase 13amp Brown = live... - Page 8 Manually filling the machine valve situated inside the left hand side panel (looking at the machine from the operators side). It is a chrome valve with a black lever. Boiler Water Cold water by-pass valve...
- Page 9 Boiler Water Cold water by-pass valve Ensure the water is turned on then move the lever to the vertical position to Locate the sight glass on the front of the machine on the left hand side as illustrated. Full Empty Once the correct water level has been reached close the water by-pass valve by turning to the horizontal position again.
-
Page 10: Turning The Machine On For The First Time
Turning the machine on for the first time Warning: To avoid serious damage to the elements or pump never turn on power before the water level has been reached in the sight glass . Switch the machine on. Open the steam valve to allow the air to vent. An air release create a false pressure. -
Page 11: Pressure Gauge
Pressure Gauge The heat exchanger, mains water pressure, co ee brew pressure and expanded pressure is shown on the left hand scale of the pressure gauge The steam pressure is shown on the right hand side gauge and should be about 1 BAR when the co ee machine is hot and up to pressure. -
Page 12: Turning The Machine On
Turning the machine on... - Page 13 Loading the filter holder and making coffee...
- Page 14 Semi-auto Electronic/Auto Electronic programming coffee measures...
-
Page 16: Steaming And Frothing
Steaming and Frothing... - Page 17 ?????
- Page 19 Backwash cleaning procedure with and without detergent...
- Page 20 Turning the machine on...
- Page 22 Maidaid Distributed by: Maidaid-Halcyon The Engine Shed Top Station Road Brackley Northants NN13 7UG Tel: 0845 130 8070 email: sales@maidaid-halycyon.co.uk www.maidaid.co.uk Manufactured in the UK...
