Exacom Glass Door Smart Lock User Manual

Glass Door Smart Lock User Manual

Recommended door type

Glass thickness

Operation power

Packages included

Keypad function ( in programming mode )
Left Cursor
Menu/Cancel

To enroll new user

Enter programming mode by long press C/M for 2 ~3 second , select EMPLOYEE -> OK
Select REGISTER -> OK , go to Employee ID by clicking Keypad 2 (Up cursor) then OK
Assign yourself an ID (from 1 to 999) then OK
Go to FINGER PRINT-> OK , put same finger print for 2 time for confirmation enroll. You can
continue to enroll other finger print by press OK again
** 1 user id can enroll up to 4 finger print
You can continue go to IDCARD/TeleControl -> OK , to enroll for ID Card access by touch ID card
near to finger print sensor. Or you can enroll remote control by clicking remote control transmitter
key button
** only ID CARD OR REMOTE CONTROL is allow in this option

To edit user

Enter programming mode by long press C/M for 2 ~3 second , select EMPLOYEE -> OK
Go to VIEW USER and select user then OK
You can adding other enrollment type such as password or modify ID CARD / TeleControl
Enrolled finger print CANNOT be modify or edit. You need to DELETE user then to enroll with new
: Full Tempered Glass Single Door (frameless)
: 10mm ~ 12mm
: 4 pcs of AA Battery , emergency recharge door with power bank
: Door lock unit and mounting bracket, mini USB adapter,
Remote control, proximity card
Down Cursor
Up Cursor
Right Cursor
Confirm / Enter
