Models:
E-Motor Assembly Instruction
HA6/1410-4, XXX
for Installation in Motor Casings with Push Fit,
as of type key 019
Series:
ONLY to be serviced by authorised specialists
Repair Information
Release: 2008-09-26
Bock Kältemaschinen GmbH
Benzstraße 7
72636 Frickenhausen
Germany
HG(HA)4
HG(HA)5
HG(HA)6
Internet
www.bock.de
E-Mail
mail@bock.de
Tel.
+4970229454-0
FAX
+4970229454-137
Advertisement
Summary of Contents for Bock compressors HA6
- Page 1 Models: E-Motor Assembly Instruction HA6/1410-4, XXX for Installation in Motor Casings with Push Fit, as of type key 019 Series: HG(HA)4 HG(HA)5 ONLY to be serviced by authorised specialists HG(HA)6 Repair Information Release: 2008-09-26 Bock Kältemaschinen GmbH Internet www.bock.de Benzstraße 7 E-Mail mail@bock.de...
-
Page 2: Liability And Warranty
Safety Information Contents Liability and Warranty ........................2 Montageanleitung für explosionsgeschützte Verdichter EX-HG4+5+6 Installation instructions explosion-proof compressor EX-HG4+5+6 Additional Safety Information ......................2 Instructions de montage des compresseurs protégés contre les risques d'explosion EX-HG4+5+6 Disassembly ............................4 Montageanleitung für explosionsgeschützte Verdichter EX-HG4+5+6 Installation instructions explosion-proof compressor EX-HG4+5+6 Inhaltsverzeichnis Contents Sommaire... - Page 3 Safety Information Important prerequisites DANGER Risk of electric shock Before you carry out any repair work, disconnect the compressor from the electricity network. Turn the main switch to "O" (OFF). Secure the main switch against an unauthorised restart. WARNING The heavy weight of the compressor and the constricted installation dimensions can potentially be dangerous.
- Page 4 Disassembly Disassembly 3.1 Depressurising the device WARNING The compressor is pressurised with a refrigerant. Remove the protective cap on the high pressure joint (HP) and the low 28 bar pressure joint (LP) and then connect the manometer. Remove the protective cap and open the valve. Danger of suffocation! Collect the refrigerant as per the instructions.
-
Page 5: Draining The Oil
Disassembly 3.2 Draining the oil NOTE Do not dispose of oil in domestic waste. Dispose of the old oil environmentally and observe national regulations. Remove the oil drain screw and the oil strainer. ¾ While the oil drains out you can perform the next step. Inspect the condition of the oil. - Page 6 Disassembly 3.3 Removing the air guide hood (only for HA)
- Page 7 Disassembly Disconnecting the electrical connections Do not damage any cables or component parts. Damaged parts must be repaired or replaced immediately. Disconnect the electrical connections in the terminal box. ¾ Remove the terminal board. ¾ Disconnect the electrical connection of the ventilator (only for HA). ¾...
- Page 8 Disassembly 3.5 Removing the motor casing WARNING The heavy weight of the compressor and parts can potentially be dangerous; risk of falling, danger of crushing. Use a supporting base. You must align the parts in order to remove them. ATTENTION! If you open the casing, the residual oil flows out.
-
Page 9: Removing The Stator
Disassembly 3.6 Removing the stator WARNING The heavy weight of the stator can potentially be dangerous; risk of falling, danger of crushing. Take appropriate measures to provide a secure location for the stator. Prevent inadvertent rolling. Remove the stator screws. ¾... - Page 10 Montageanleitung für explosionsgeschützte Verdichter EX-HG4+5+6 Assembly Installation instructions explosion-proof compressor EX-HG4+5+6 Instructions de montage des compresseurs protégés contre les risques d'explosion EX-HG4+5+6 Assembly Inhaltsverzeichnis Contents Sommair To assemble, reverse the order of the steps. Note any particular features such as Seite Inhalt Page...
- Page 11 Instructions de montage des compresseurs protégés contre les risques d'explosion EX Montageanleitung für explosionsgesch Installation instructions explosion-pro Inhaltsverzeichnis Contents Instructions de montage des compresseurs proté Seite Inhalt Page Contents Assembly Allgemeine Sicherheitshinweise General s Inhaltsverzeichnis Sicherheitshinweise Aus/-Einbau Safety ins Seite Inhalt removal/i 4.2 Connecting the electrical connections to the terminal box...
- Page 12 4.2 Connecting the electrical connections to the terminal box Terminal assignment on the terminal board with part winding connection (PW Y / YY) Partial winding 1 White Terminal board ATTENTION! Make sure that you use the correct connection on the underside cable trees! Red stripes...
- Page 13 Installation instructions explosion- Instructions de montage des compresseurs Inhaltsverzeichnis Assembly Seite Inhalt Allgemeine Sicherheitshinwe 4.3 Assembling the motor casing Sicherheitshinweise Aus/-Ein Montage/-Demontageanleitun zu folgenden Service-Bausät WARNING Ventilplatte The heavy weight of the compressor and parts can potentially be 9-11 Ölpumpe 12-14 Flanschabsperrventil (LP) dangerous;...
- Page 14 Installation instructions explosion-proof compressor EX-HG4+5+6 Instructions de montage des compresseurs protégés contre les risques d'explosion EX-HG4+5+6 Inhaltsverzeichnis Contents Installation Seite Inhalt Page Contents Allgemeine Sicherheitshinweise General safety instructions 4.4 Assembling and making the electrical connections Sicherheitshinweise Aus/-Einbau Safety instructions for removal/installation Montage/-Demontageanleitung Installation/disassembly...
- Page 16 www.bock.de Sehr geehrter Kunde, Bock-Verdichter sind hochwertige, zuve Vorteile in vollem Umfange und über de Bock Kältemaschinen GmbH können, beachten Sie unbedingt die fol Montage, Betrieb und Zubehör wenden Benzstraße 7 Kältefachgroßhandel bzw. unsere Vertr 72636 Frickenhausen +49 7022 9454-0, via e-mail: mail@bo chigen Raum steht darüber hinaus die k Telephone +49 7022 9454-0 bis samstags zwischen 8 und 21 Uhr zu...
