o2ones AVOIR RING User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
In order to use the product correctly, please read
the instruction manual carefully before use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVOIR RING and is the answer not in the manual?

Questions and answers

Summary of Contents for o2ones AVOIR RING

  • Page 1 User Manual In order to use the product correctly, please read the instruction manual carefully before use.
  • Page 2 Before using the product Avoir Ring Bridge is a smart wearable device, please use the product according to the precautions described below. The ring can be used in conjunction with Android 6.0 Marshmallow or higher OS and 2.4GHz Bluetooth 4.1 (BLE) ...
  • Page 3 You can check the new features that will be developed in the future on our website, and can see how to use  them in various user environments. (Home page: http://www.avoirring.com/) Safety and warning sign when using the product. Instruction sign when using the product. Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 4: Table Of Contents

    How to charge the ring Music player control Precaution when using the charger Camera control Receive Call Install apps and connect the ring Read messages install apps Send SOS messages connect the ring Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 5: Product Component

    Product component Charging Cable Avoir Ring Charger please make sure all products are included in the package.  Actual product may differ from the image above.  Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 6: Ring Name And Specification

    15mA Li-Po Battery Standby mod 7 days Operation mode 5 days Charging time 90 minutes Connectable distance Within 10 meter Waterproof · dustproof IP67 The specifications are subject to change without notice. Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 7: Charger Name And Specification

    Charger name and specification Charger specification ① cover ② ring charge LED status indicator ③ charging terminal ④ body ⑤ Micro 5 pin USB Cable Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 8: How To Charge The Ring

    ① Put the bottom of the ring to the charger. ② When it’s connected, LED light appears on the ring. Please refer to the note below for color of light. Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.
  • Page 9 Check the charging terminal position and insert it in the  correct direction. If you put it in the opposite way, it will not light.  Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 10: Precaution When Using The Charger

    Please fully charge battery before first use or after a long period of time, Be sure to use the cables packaged with the Avoir Ring or certificated charging cable and adapter. When it is charging to a computer or a laptop via a USB cable, it may cause a slow charging speed due to low ...

  • Page 11: Install Apps

    Install apps and connect the ring l how to install Avoir Ring apps To connect your ring with your smartphone, you'll need to install the "Avoir Ring" App on your smartphone. Please install the "Avoir Ring" App from Google Playstore.

  • Page 12: Connect The Ring

    3) Concerts, baseball grounds, etc. In a radio interference environment, the ring connection may be unstable. 4) Notification may vary depending on your Android version. 5) If you fail to link your ring continuously, please contact the o2ones service center +82 31-716-9452 Please allow Avoir Ring App to access below items for ①...
  • Page 13 -1 Enable Avoir Ring to send notification -2 Press the allow button in the notification window, ② ② make sure it is activated, then press the Back button ① ② Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.
  • Page 14 Install apps and connect the ring Connect the ring -1 Select the Avoir Ring App in Allow Access -2 Enable usage tracking. Once activated, press Back ③ ③ button twice menu ① ② Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.
  • Page 15 FAQ below Unique number of ring Green LED blinking before ring connection.  If you can’t see green LED, please press the ring  button once. Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.
  • Page 16 Connection display color change(2 styles)  ① Green ② Green -> Red -> Green Battery The connection indication may takes time  according to the reception and status. Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 17: Basic Operation

    Forward (execute / go forward, etc.) Double press Within 1 second Stop (go backward / run camera, etc.) 1 second to Recording function etc. 2 seconds Long press More than 4 SOS, etc. seconds Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 18: How To Use The Ring

    1) If you select App on the “User App” setting, the selected App is launched with single click ① ② Press “User App” setting Select one App among Apps on your phone Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 19: Led Notification

    The LED status indicator may not come out clearly when the ring's battery is low.  The LED does not work in SOS mode if the SOS feature is turned off in the Avoir Ring app.  Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 20: Vibration Notification Method

    Click on the vibration icon at (Notification setting ON) senders for vibration notification the top to set the vibration Messenger alerts will only be activated when name of sender and contact name are same Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 21: Smartphone Theft Prevention

     How to use 1) This function can only be enabled by activating the loss prevention feature in the Avoir Ring App menu. 2) You may select the person who will receive the location information on the Anti-Lost setting menu.

  • Page 22: Activate Voice Assistantapp

    BixBy, Google Assistant, etc. must be configured, and you need to have an Appset up as the default Voice Assistant  Appon the Android platform. If your smartphone is locked, you can register your Avoir Ring as a trusted device in the SmartLock setting so that  you can run the Voice Assistant Appeven when it is locked.

  • Page 23: Recording Function

    2) If you want to stop recording, press the Ring button twice. Then, the recorded voice will be saved automatically. 3) Check recorded voice files: My Files app> Internal storage> Avoir Ring folder If there is not enough memory space, recording may not be possible.

  • Page 24: Music Player Control

    When using the music player, if you want to run the speech assistant app, please launch after pausing the music.  Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 25: Camera Control

    How to use the ring Camera control Android phones except Samsung smart phone, you can download the 'Avoir Ring Camera' app from the Google Store  and use it after installation. Function 1) With the smartphone screen off, press the button twice to launch the camera. While the camera is running, 'single press' takes a picture and 'long press' starts and records video right away.

  • Page 26: Receive Call

    Hang up the While calling Within 1 second Double press Hang up the phone phone 1 second to 2 Screen Off / Home screen / Long press seconds Calling screen Calling screen Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 27: Read Messages

    / Messenger chat window and reads the message. 2) You must activate the “Read a message” function in the Avoir Ring Appmenu to read the message. 3) If you want to turn off message reading, please turn off message reading function in the Avoir Ring Appmenu.

  • Page 28: Send Sos Messages

    2) You can assign up to 5 contact persons for sending a SOS text message and 1 contact person for making a SOS call. How to use 1) In the SOS item of the Avoir Ring App menu, specify the contact who will receive the SOS message. It is specified separately from the contact set in the smartphone loss prevention function.

  • Page 29: Appendix

    Be careful when using the product because the waterproof and dustproof function may be weakened over  time. Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.
  • Page 30 Appendix We highly recommend you to wear Avoir Ring on your Index finger so that you feel comfortable to press  the button with your thumb Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 31: Faq

    Please remove the (Avoirring_xxx) from the registered device item in the Bluetooth setting menu of the smartphone When the ring is disconnected from Avoir Ring app, you should press the button on the ring more than 4 seconds to reset the ring You should try re-connection after disconnecting by pressing ‘Disconnect Ring’...
  • Page 32 Make sure that both Allow notification access and Allow access to usage information are set to Allow. Please check whether the above functions are activated in Avoir Ring app. If the above function does not work, contact our service center.

  • Page 33: Fcc

    This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Copyright ⓒ 2017 o2ones Co ., Ltd All rights reserved.

  • Page 34: Copyright

    Copyright ⓒ 2017 (주) o2ones This User's Guide is copyrighted under copyright law. You may not reproduce, transmit, distribute, translate, or change to electronic or machine-readable in any form without the prior written consent of o2ones Corporation. Product Warranty The warranty period of this product is calculated from the date of purchase.
  • Page 35 For A/S inquiries, please contact the following address. Customer center number : +82 31-716-9452  Email : o2ones@o2ones.com  If you know the product model name and the part number on the bottom of the charger before contacting us, you can get service faster.
