- Page 1 FROMM Installation Instr FS4.0146.05.EN02.doc FROMM AUTOMATIC Cutting device Series FS400 / FS401 / FS402 / FS403 Item No FS4.0146 Rev.02 It is forbidden to duplicate this manual or parts of it in any way or any form without written permission of the author © 2016...
-
Page 2: Table Of Contents
FROMM Installation Instr FS4.0146.05.EN02.doc INDEX Page INDEX 2 - 3 General 5 – 6 Safety instructions Warnings 8 – 12 Installation Maintenance instructions It is forbidden to duplicate this manual or parts of it in any way or any form without written permission of the author © 2016... - Page 3 FROMM Installation Instr FS4.0146.05.EN02.doc Opgelet! Leest U in elk geval de gebruiksaanwijzing, vooraleer de machine wordt opgesteld, geïnstalleerd en in gebruik genomen wordt. Daardoor zorgt U voor Uw eigen veiligheid en vermijdt U schade aan Uw machine. Achtung! Lesen Sie unbedingt die Gebrauchsanweisung vor Aufstellung-Installation-Inbetriebnahme.
-
Page 4: General
GENERAL This manual is only intended for a automatic cutting device, mentioned at page one, as delivered by FROMM Stretch Wrapping Division. FOR EVERYTHING IN THIS MANUAL IS VALID, IF APPLIED! For safety reasons the entire instruction manual should be read before setting in operation the machine/installation, solving failures and executing maintenance. -
Page 5: Safety Instructions
The following conditions have always to be satisfied, unless otherwise indicated in other instructions in this manual. This product has been delivered by FROMM Stretch Wrapping Division and may only be applied for FS400 / FS401 / FS402 / FS403 wrapping machines. - Page 6 FROMM Installation Instr FS4.0146.05.EN02.doc The supplier will do the training of the operating personnel. If not, the training will have to be done properly by the company that takes care of the installation. This option is designed and implemented conforming to the safety laws in force. Consequently, no intrinsic fire risks are envisaged when the machine is used normally ...
-
Page 7: Safety Instructions
FROMM Installation Instr FS4.0146.05.EN02.doc WARNINGS The mean weighed noise level of the machine is less than 80 dBa. It is possible that, depending on the applied film, during wrapping of the pallets incidentally a noise level with a maximum of 80 dBa will be measured. -
Page 8: Installation
FROMM Installation Instr FS4.0146.05.EN02.doc Cutting device Kit FS4.0146 (If you need, for the connection look also 3 pages of ELS at the end of this manual). Installing the power supply FS4.1283: Install the power supply FS4.1283 into the switch cabinet, by using the 2 screws N1.1921 and the 2 plain washers N1.6115. - Page 9 FROMM Installation Instr FS4.0146.05.EN02.doc Open the cable later cable duct and the cable duct just above the PLC Open these two cable duct’s Connect red wires marked “21/20” from the power supply FS4.1283 to the terminal 21/20 of the PLC.
- Page 10 FROMM Installation Instr FS4.0146.05.EN02.doc Cutting device Kit FS4.0146 Installing the power Cutting device group FS4.0133: Remove the yellow top cover from the stretch unit, open the door and place the cutting device, inside at the left topside of the carriage.
- Page 11 5. Close the connection box, fix the cable to the stretch unit by using 2 plastic tie-wraps. Re-install the yellow protection cover on the stretch unit. 6. Switch on the machine again 7. Enter into the hidden FROMM technical menu: Hold down the key Followed by pressing the keys in this sequence...
-
Page 12: Installation
Check if the pre-selected tension is very low. If yes you have to decrease the value of the analogue sensor in the hidden technical menu. Enter into the hidden FROMM Technical menu: Hold down the key Followed by pressing the keys in this sequence... - Page 13 FROMM Installation Instr FS4.0146.05.EN02.doc Followed by pressing more times the “stop” key, you can exit from the menu. Try if the cutting device works. If not repeat the steps after step 8. Decreasing more the value of the analogue sensor.
-
Page 14: Maintenance Instructions
FROMM Installation Instr FS4.0146.05.EN02.doc MAINTENANCE INSTRUCTIONS FOR OPERATORS SAFETY! First switch off the main switch and lock it before carrying out maintenance on the installation. Take care, that other persons cannot put the installation in action. Take care, that the protection covers, etc. are remounted when putting the installation in action again.
