Quick-Start Instructions
MultiBoard
G8x-7xxx/8xxx
USB Hub Version with
2 Downstream Ports
1 Information available as
hardcopy, direct help and on CD
Information on setup, operation and configuration
can be obtained in these quick-start instructions,
as direct help and as operating instructions. Please
observe the general user information and the
license agreements.
The information is split up based on the following
criteria:
• The quick-start instructions essentially describe
connection of the device and software installa-
tion.
• The direct help is a component of the software.
It provides you with information on operation
where you need it. It is called up via F1.
• The operating instructions describe operation
and configuration. They are contained in a PDF
file on the accompanying CD (CD-ROM/Manu-
als). You can read the desired content on the
screen or print it out here.
By supplying only the most essential information as
a printout, we are reducing the unnecessary use of
paper and thus making our contribution towards
environmental protection.
2 Advantages of the keyboards
• Cherry MX technology with "Gold Crosspoint"
contacts (G80)
• Cherry FTSC technology (G81)
• Robust and reliable
In addition to the functions of a standard key-
board, the keyboards feature the following addi-
tional functions, depending on the variant:
• Magnetic card reader
• Touchpad, mouse replacement
• Blank keys which can be labeled
• Additional, freely assignable keys
• The keys are freely programmable via the
Cherry Tools software
You can connect other USB peripheral devices to
the two USB ports (downstream ports).
Caution
Danger is present if the current consumption is
too high!
Short-circuits and subsequent damage may occur
if defective or unsuitable devices are connected to
the USB ports.
Only devices with a maximum current consump-
tion of 100 mA (low-power peripherals) may be
connected to the USB ports.
The following standard functions of the keyboard
are available immediately after plug-in, with operat-
ing systems supporting USB:
• Standard keys
• Numeric keypad
• USB ports (downstream ports)
• Touchpad (if present)
