KYK Co.,Ltd promises to treat every customer fairly and
respectfully with their health and happiness our number one priority.
The head office address / Manufacturing Company
#406~410 Sun-il technopia, 555 Dunchon road, Joongwon-Gu,
Sungnam City, Kyunggi-Do, KOREA
TEL. 82-31-777-3939
FAX. 82-31-777-3456
Made in Korea
Advertisement
Related Manuals for KYK Hyd-Hisha
Summary of Contents for KYK Hyd-Hisha
- Page 1 KYK Co.,Ltd promises to treat every customer fairly and respectfully with their health and happiness our number one priority. The head office address / Manufacturing Company #406~410 Sun-il technopia, 555 Dunchon road, Joongwon-Gu, Sungnam City, Kyunggi-Do, KOREA TEL. 82-31-777-3939 FAX. 82-31-777-3456...
- Page 2 USER MANUAL Hyd-Hisha...
- Page 3 Thank you for Being our Customer! Dear Customer, We sincerely appreciate your purchase of KYK alkaline water Ionizer medical substance producer and we hope your health and happiness. Before operating the product, you must read the user manual carefully. You can know not only how to use but also the strong points of the...
- Page 4 Table of Contents Special Features Major Components Parts and Features Before installation Installation Installation checklist How to use When to change the filters How to change the filters Summary of Operation Notices Notices for Safety Product Specifications Warranty Registration ※Note: This product is a medical substance producer and you should read this manual carefully before operating the product.
- Page 6 Normal use for adults Normal use for adults Water to take medicine or drinking water (Purified water) 2. KYK’s patented invention of the platinum-coated titanium electrode structure and electrolyzer system 3. Instant Rich Hydrogen Generation 4. High-performance, high-efficiency SMPS power control system with little power loss and low heating 5.
- Page 7 Body Front Back ❷ Control buttons ❶ Faucet ❹ ❺ Speaker Filter cover ❸ Filter lifespan indicator ❾ Inlet port ❹ ON/OFF Valve ❽ Ozone port ❻ Power cable ❼ Spare port Bottom Ozone Port Spare port Inlet Port Accessories Diverter valve 6x8 90°...
-
Page 8: Control Panel
Control Panel Filter lifespan indicator Ozone Hydrogen water water Ozone Water Level1 Hydrogen water 600~800ppb Purified water Level 2 Hydrogen water 800~1000ppb Level3 Hydrogen water Clean/Set 1000~1200ppb Water control valve Select water type and turn the valve ON. Clean/Set:... - Page 9 Do not tilt the product Install the product at least 10 cm away from walls. Connect the ionizer only to cold water Keep the product in dry places, avoid high moisture supply. Damage resulting from areas or direct sunlight. connecting the ionizer to hot water supply is not covered by the warranty.
- Page 10 Lock the tap water; connect the device to cold water supply. The hose included with the device is 6ø:1/4 inch.
- Page 11 Water Entrance The connecting hose with product for incoming water...
- Page 12 Switch valve of incoming water All hookup part of pipe arrangement has to be covered by teflon tape for avoiding the leakage and you control the bounding number of tape for keeping the level of a horizontality and a perpendicularity. When you decompose and reassemble the product, if you give the over force, it will be possible to leak after assembling the product because of a pipe arrangement distortion of raw water, a break out of rubber packing and a breakage.
- Page 13 Turn off the water control valve before inlet water connection Firmly attach 90° elbow fittings to inlet and ozone port on the back of the machine. Install the water pressure regulator before the machine and connect plastic hose to fitting on inlet port CAUTION Inlet, ozone port check...
- Page 14 Firmly connect plastic hose to fitting of ozone port Open the diverter for water supply and power ON. With audio alarm, machine is ready to be used all LED lighted on for 3 sec. Default setting is Level 2 Hydrogen Water. Leave the machine work for 2 min.
- Page 15 Diverter installation may cause pipe particles or rusts. Run the water out to your tap to protect the machine. How to check the water pressure and set up If the water pressure is too low or high, the buzzer will be sounded, when you drain the water. The machine will sound the warning, if the water pressure is lower than 0.5liter, higher than 3.5liter.
-
Page 16: How To Operate
How to operate 1. Place the faucet on the right place for water dispense. 2. Press the button for operation and open the ON/OFF Valve. You will see lots of hydrogen in water. Take hydrogen water immediately. 3. Appropriate water flow rate is 0.7~0.8ℓ/min. 4. - Page 17 Filter replacement time: ■ KYK machine shall give you notice once installed filter is expired by capacity and time. For bad inlet water, place outer filter before the machine. In case of any abnormal scent from the dispensed water, replace filter with new one even the filter is available.
-
Page 18: How To Change The Filters
How to change the filters Close the diverter Unplug the machine. Remove the filter cover. Pull the filter forward to take it out. - Page 19 Pull electric ware out from Grab the filter and rotate it the filter chip. counter-clock-wise. Pull it out. Please remove the safety seal of the new filter. Place it on the filter holder and press. Close it by turning it clock-wise. Make sure that the rubber ring in the connection between the filter and the main body is not detached or jammed.
- Page 20 Connect the wire to the filter chip. Close the filter cover. Plug the power in and drain water Push the filter into the machine. for 2~3 minutes to remove any particles from the filter..
- Page 21 ■Do not use this product for any purpose other than what’s described in this manual. ■Do not modify this product intentionally. ■Do not place heavy objects on this product. ■Do not lift this product body holding the stainless steel tube, it will break. ■Always keep the disposal outlet open so water can drain.
- Page 22 Keep out of direct sunlight or heat. To avoid impure water and malfunctioning of the KYK product. ■ Be sure to only supply clean, quality water to the KYK Product. Do not hook up directly to a well, lake, river, etc.
- Page 24 Filter indication ③ Filter expires by time and capacity, which comes first . ④ Use KYK genuine filter only. KYK is not responsible for any damage caused by faked filter use and user’s mis-use. Filtering Material Composite filter Notification...
-
Page 25: Warranty Registration
Warranty Registration Purchase Terms of one year parts and labor. Date Warranty Address Customer’s Name Phone No Representative Name Seller Phone No 1. Our company will pay for repair, labor and shipping for one year guarantee performance and operations. If repair of the produce is not possible, we will replace the product. 2.
