- Page 1 TIM & TOM complete PA system 600W & 1000W...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT ENCLOSURE THAT MAY BE OF A SUFFICIENT MAGNITUDE TO CONSITUTE A RISK OF ELECTRIC SHOCK TO PERSONS. - Page 3 WARNINGS PRECAUTIONS WARNINGS Read carefully this manual and follow these precautions before operating the device Keep this manual for possible future needs Pay attention not to pour liquids onto the device and do not operate in conditions of excessive humidity Do not install the device close to sources of excessive heat, do not expose it to direct solar radiation and do not position it without protection in a dusty environment Be sure that the main voltage does not exceed the value indicated on the back panel...
-
Page 4: Practical Advice
INTRODUCTION TIM is a 600W (350 +125+125) analog amplification system consisting of a compact active subwoofer and two passive satellites. The former Pocket 1 system has been re-engineered for professional use, featuring an enhanced design and several new control features, such as a mono/stereo switch, for greater flexibility. The subwoofer is constructed using BJT technology, incorporating a linear power supply for excellent bass response and efficient stereo effect. -
Page 5: Back Panel
1. BACK PANEL mono T I M S U B www.schertler.com MAX SYSTEM POW. 600 W SUBWOOFER mono POWER 350W DESIGNED IN TO REDUCE RISK OF FIRE, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, SWITZERLAND REPLACE ONLY WITH THE SAME TYPE AND RATING OF FUSE. - Page 6 2. TIM/TOM SAT REAR PANEL 2.1 INPUT Sat input, connect to power out L/R with speakon cable...
- Page 7 3. TIM/TOM INCLUDE 1 X Active Subwoofer 2 X Passive SAT speakers 1 X Power connection cable 2 X Speakon Cable 1 X Warranty certificate 1 X User manual...
- Page 8 TECHNICAL SPECS - TIM Specification TIM SUB TIM SAT Frequency response 50 Hz - 150 Hz 150 Hz - 20 kHz ---------------------------------------- ---------------------------------------- ---------------------------------------- Sensitivity (1W-1m) 91.5 dB 92 dB ---------------------------------------- ---------------------------------------- ---------------------------------------- SPL max 117 dB 113 dB ----------------------------------------...
- Page 9 POLAR PATTERN - TIM 100Hz 300Hz -180 -180 170 175 1 80 -175 -170 -165 170 175 1 80 -175 -170 -165 160 165 -160 -155 160 165 -160 -155 -150 -150 -145 -145 -140 -140 -135 -135 -130 -130 -125 -125 -120...
- Page 10 TECHNICAL SPECS - TOM Specification TOM SUB TOM SAT Frequency response 45 Hz - 150 Hz 150 Hz -20 kHz ---------------------------------------- ---------------------------------------- ---------------------------------------- Sensitivity (1W-1m) 93.5 dB 94.5 dB ---------------------------------------- ---------------------------------------- ---------------------------------------- SPL max 121 dB 118 dB ---------------------------------------- ---------------------------------------- ---------------------------------------- Woofer 12”...
- Page 11 POLAR PATTERN - TOM 100Hz 300Hz -180 -180 170 175 1 80 -175 -170 -165 170 175 1 80 -175 -170 -165 160 165 -160 -155 160 165 -160 -155 -150 -150 -145 -145 -140 -140 -135 -135 -130 -130 -125 -125 -120...
- Page 12 “COMMON SENSE” AND THUS, MISUSE OF OUR PRODUCTS ARE NOT COVERED UNDER RIGHTS OBTAINED THROUGH OUR WARRANTY POLICY OR THAT OF INTERNATIONALLY RECOGNIZED TERMS AND CONDITIONS. SCHERTLER SA IS CONSTANTLY AIMING TO IMPROVE ITS RANGE OF PRODUCTS THEREFORE, SCHERTLER SA RESERVES THE RIGHT TO AMEND PRODUCT SPECIFICATIONS WITHOUT NOTICE.
