- Page 1 MYDAX, INC. INSTRUCTION / OPERATION MANUAL 1M150W WATER COOLED CHILLER MYDAX, INC. 12260 Shale Ridge Road Auburn, CA 95602 (530) 888-6662 FAX: (530) 888-0962 http://www.mydax.com...
-
Page 2: Table Of Contents
INSTALLATION ........... 6 Table of Contents FRONT PANEL CONTROLS ....... 8 ALARM & ERROR MESSAGES......10 DIAGNOSTIC DISPLAYS ........11 SERVICE & WARRANTY........14 1M150W SHIPPING & STORAGE PROCEDURE .... 15 APPENDIX A RS-232 INTERFACE COMMANDS DRAWINGS PARTS LIST FRAME DRAWING... -
Page 3: Specifications
Mydax, Inc. 1M150W Water Cooled Chiller SPECIFICATIONS SYSTEM CAPACITIES Net Cooling Capacity at +11°C (+52°F) 43,988 Watts or 150,000 Btu/hr Fluid Temperature Setpoint Range +8°C to +40°C Temperature Stability ± 0.5°C Recirculating Flow/Pressure 40 GPM @ 50 PSI Includes flow indication relay contacts. -
Page 4: Safety & Environmental Concerns
SAFETY AND ENVIRONMENTAL CONCERNS Your Mydax chiller was designed to give years of trouble-free operation. Features were designed into the unit to provide early warning of failure mechanisms so that catastrophic failures can be avoided. Whether a chiller is at the factory or in the field, diagnostic information gives Mydax engineers insight to the operation of each stage of the refrigeration and recirculation circuits without having to attach service gauges. - Page 5 Refrigerants are fluorocarbon type materials and subject to environmental regulations. The compressor uses POE oil; this MSDS is available from Mydax upon request. The compressor is hermetically sealed and no service should be required. In the event that cleanup is necessary, absorb oil with oil absorbent material and dispose of as a hazardous waste.
-
Page 6: System Overview
The superheat valve passes only enough refrigerant to maintain the proper gas temperature at the suction inlet of the compressor. Using this technique, Mydax is able to run in load conditions of zero to full load and all combinations in between. - Page 7 Mydax, Inc. 1M150W Water Cooled Chiller System Electrical Diagram Refer to drawing #D2923, the system electrical diagram. The central component of the electrical system is the M1001 controller. It is microprocessor-based and communicates with and/or controls various other circuit boards and components.
-
Page 8: Installation
This display indicates that the microprocessor is initializing. After a few seconds, the controller will finish initializing and the "Warm-up Delay" message will return to simply "Mydax". Leave the unit turned on while hooking up the following plumbing connections. This will allow time for the crankcase heater to warm the compressor and separate the oil from the refrigerant. - Page 9 300K and 500K ohms. On a yearly basis, or if the unit is unable to maintain resistivity to acceptable level, replace with Mydax part# F1003. This mixed-ion resin cartridge filter is only available from Mydax.
-
Page 10: Front Panel Controls
Water Cooled Chiller FRONT PANEL CONTROLS All Mydax chillers are controlled by a microprocessor which is accessed via the system control panel. System controls are simple, yet powerful and in concert with built-in diagnostics and error messages, are exceptionally comprehensive. - Page 11 "." (DECIMAL): Display shows model number and software revision date and copyright: Model # Date Copyright 2003 Mydax, Inc. RUN PUMP: Inactive in this system.. X & Y: For future use. See Test Panel 9 in the Diagnostic Displays Section.
-
Page 12: Alarm & Error Messages
Water Cooled Chiller ALARM & RROR MESSAGES A unique feature of Mydax systems is the error messages displayed on the 2 by 40-character liquid crystal display (LCD). The microprocessor constantly checks various points and parameters throughout the system and automatically displays messages when error conditions are sensed. -
Page 13: Diagnostic Displays
Water Cooled Chiller DIAGNOSTIC DISPLAYS Mydax chillers are provided with a computerized self-diagnostic capability. This system is equipped with 9 different test panels, which are accessed by pressing the TEST key, followed by the test panel number. Diagnostic mode is terminated... - Page 14 Mydax, Inc. 1M150W Water Cooled Chiller maintain temperature stability, and give the magnitude and timing of the change. The center of the display shows readings for the RTD "Zero" and "Gain" calibration resistors. Precision 100Ω and 120Ω resistors (0.1% tolerance or better, representing ideal nominal RTD's) are used as a reference.
- Page 15 Mydax, Inc. 1M150W Water Cooled Chiller TEST PANEL #8: Fill Tank ! Alarms: Run 356d 11:31:25 The top left side of this display shows the alarm (error message) history. If there have been no alarms since the last history reset, the display reads "No Alarms". If alarms have occurred, the display shows them in sequence, like the main display.
-
Page 16: Service & Warranty
SERVICE & WARRANTY If a unit malfunctions, please contact the Mydax Service Department as soon as possible. Many small problems can lead to large problems if not dealt with immediately. Please have the serial number and model number on hand when calling. -
Page 17: Shipping & Storage Procedure
Plug the TANK IN, TANK OUT, FILL and DRAIN fittings to avoid leakage of any residual coolant during shipment or storage. FAILURE TO PERFORM THESE STEPS PRIOR TO SHIPMENT MAY VOID THE WARRANTY. Call Mydax for shipment preparation help, if needed, at (530) 888-6662 Designed for Lockheed Martin...
