Knowledge Base
Article Type: Instructions
Mold Installation for: Models
Pit Models 10, 12, 22, 16.
Description:
Instructions on "How to" properly install a mold in machine models;
Floor Level – 22HF, 16HF and 1600, Pit Models – 10, 12, 22, and 16.
Never work on, clean or service this unit, control panel or any machine or open
or remove any protective cover, guard, grate, door, or maintenance panel until
the power or energy sources has been turned off, locked out / tagged out, and all
moving parts have come to a complete stop and or blocked to prevent
movement. Machinery is dangerous – avoid personal injury and or death by
following manufacture, Local, and OHSA safety procedures. Contact Columbia
Machine for safety decals, guards, horns and beacons.
22HF, 16HF, 1600,
WARNING
Advertisement
Table of Contents
Summary of Contents for Columbia 22HF
- Page 1 Description: Instructions on “How to” properly install a mold in machine models; Floor Level – 22HF, 16HF and 1600, Pit Models – 10, 12, 22, and 16. WARNING Never work on, clean or service this unit, control panel or any machine or open...
- Page 2 Mold Installation for Model 22,16,1600 We have found in recent months that block machine operators are installing the mold improperly. This improper installation practice will cause unnecessary wear on mold hanger bracket and the die supports. 1. Assemble the mold on a very flat surface, such as a machined flat steel table. Do not assemble molds on steel pallets from the machine or on wooden surfaces.
- Page 3 4. Next, using a straight edge, inspect the die supports for flatness. Verify the mounting surfaces are flat; this allows the mold to mount flat against the die supports. If these surfaces are not flat, they can cause the mold to break bolts, or worse, cause the vibrator shaft to fail.
