- Page 1 SIGNAL ADDER CONVERTER XS-110 User manual Signal Adder Converter MAN-EN-DE-XS110-01.02_13...
- Page 3 The instrument described in this technical user manual is a device suitable for application in a specialized technical area. DLG products are submitted to a strict quality control process. However, industrial control electronic equipment can cause damage to machinery or controlled processes in the event of any failure or improper operations and may even endanger human lives.
-
Page 4: Table Of Contents
Contents PRESENTATION ....................6 SPECIFICATION ....................7 APPLICATIONS ....................8 TECHNICAL SPECIFICATIONS ................9 DIMENSIONS ..................... 10 OPERATION ....................... 11 Default triggering ....................... 12 Sequential triggering ......................12 MOUNTING......................13 FRONT PANEL SETTINGS ................15 Keys ..........................15 LEDs ..........................15 SETTINGS ...................... - Page 5 Configuring for 10 PNP sensors ................18 Sequential triggering ......................19 Configuring for 8 NPN sensors .................. 19 Configuring for 10 PNP sensors ................19 MECHANICAL INSTALLATION ................. 20 RECOMMENDATIONS ..................21 WARRANTY ....................... 22...
-
Page 6: Presentation
It also provides a power supply for sensors with short circuit protection. Among the possible applications, level measurement and control stands out. The XS-110 is built in a plastic box for DIN rail mounting. Page 6 of 24 XS-110 User Manual MAN-EN-DE-XS110-01.02_13... -
Page 7: Specification
Inverted default triggering comprises only the last triggered sensor. Examples: • XS-110 : Default triggering Signal Adder Converter. Output changes accordingly with the last triggered input sensor; • XS-110/S: Sequential triggering Signal Adder Converter. Except the first input channel, output changes only when input is triggered in pairs, i.e., accordingly with the last and penultimate triggered input sensor;... -
Page 8: Applications
• Level measurement in grains and cereals storage silos; • Level measurement of solid products in food, ration, paints and paper industries. Page 8 of 24 XS-110 User Manual MAN-EN-DE-XS110-01.02_13 All rights reserved to DLG Automacao Industrial... -
Page 9: Technical Specifications
DIN rail Electrical connections Screw terminals IP protection IP-30 Dimensions 75 x 100 x 110 mm (height x width x length). Approx. weight 0.3 kg XS-110 User Manual MAN-EN-DE-XS110-01.02_13 Page 9 of 24 All rights reserved to DLG Automacao Industrial... -
Page 10: Dimensions
XS-110 Signal Adder Converter Dimensions DIN rail 35 mm Rail lock Figure 1 – Dimensions (mm) Page 10 of 24 XS-110 User Manual MAN-EN-DE-XS110-01.02_13 All rights reserved to DLG Automacao Industrial... -
Page 11: Operation
The output signal (0 / 4 ~ 20 mA or 0 ~ 10 Vdc) is proportional to the number of triggered inputs. Figure 2 shows operation with 6 inputs. Figure 2 – 4-20 mA and 0-10 V outputs on a XS-110 with six inputs Table 1 show the expected output (current and voltage) based on the number of triggered inputs for different XS-100 with 4, 6, 8, and 10 inputs. -
Page 12: Default Triggering
Default triggering turns the analog output a function of only the last sensor triggered. For instance, for a XS-110 configured for 10 inputs, the current output will be 20 mA only when the input is triggered, regardless of the state of the other 9 inputs. -
Page 13: Mounting
Signal Adder Converter Mounting The XS-110 shall be mounted in water, vapor and dust free areas. Its mounting position is irrelevant. A protection fuse must be provided. Figure 3 illustrates the front panel and the electrical connections. Connections must be made with shielded wire for input signals, using exclusive metalling pipe, or twisted pair cable. - Page 14 Signal Adder Converter Figure 4 – Level measurement with ten SC-100/SC-500 capacitive sensors Figure 5 – Current output connections Figure 6 – Voltage output connections Page 14 of 24 XS-110 User Manual MAN-EN-DE-XS110-01.02_13 All rights reserved to DLG Automacao Industrial...
-
Page 15: Front Panel Settings
The red LED indicates the type of sensor (NPN or PNP) that should be connected to the inputs. When lit, it indicates that a NPN sensor should be used; otherwise, a PNP sensor should be used. XS-110 User Manual MAN-EN-DE-XS110-01.02_13 Page 15 of 24 All rights reserved to DLG Automacao Industrial... -
Page 16: Settings
LED stays off. The minimum fall time is 0.1 seconds and the maximum is 20 seconds. Page 16 of 24 XS-110 User Manual MAN-EN-DE-XS110-01.02_13 All rights reserved to DLG Automacao Industrial... -
Page 17: Sequential Triggering
LED stays off. The minimum fall time is 0.1 seconds and the maximum is 20 seconds. XS-110 User Manual MAN-EN-DE-XS110-01.02_13 Page 17 of 24 All rights reserved to DLG Automacao Industrial... -
Page 18: Configuration Examples
XS-110 is configured for 10 sensors. If the XS-110 is configured for 9 or 10 sensors, and the ramp rise or fall time needs to changed, it is necessary to reconfigure following the steps described above. -
Page 19: Sequential Triggering
LED starts blinking, indicating that the XS-110 is configured for 10 sensors. If the XS-110 is configured for 9 or 10 sensors, and the ramp rise or fall time needs to changed, it is necessary to reconfigure following the steps described above. -
Page 20: Mechanical Installation
Attach the bottom of the equipment to the DIN rail. Release the lock. Make sure that the equipment is properly locked to the rail. Page 20 of 24 XS-110 User Manual MAN-EN-DE-XS110-01.02_13 All rights reserved to DLG Automacao Industrial... -
Page 21: Recommendations
XS-110 Signal Adder Converter Recommendations It is recommended to use only appropriate tools for the XS-110 installation and maintenance. It is necessary to use a “terminal’ type screwdriver for terminal connection or 1/8 with 3 mm maximum diameter, as it is the ideal format and will not damage the connector aperture. -
Page 22: Warranty
3. For repairs send the equipment along with the shipping invoices to our factory in Sertaozinho, Sao Paulo state, Brazil. DLG’s address is available at the end of this manual; 4. The owner is responsible for transportation costs and risks;... - Page 23 Notes...
- Page 24 Rua José Batista Soares, 53 Distrito Industrial – 14176-119 Sertãozinho – São Paulo – Brasil DLG reserves the rights to change this manual contentes without Fone: +55 (16) 3513-7400 notice in order to keep it updated with new product features.
