ATI Technologies Scan Alarm C14 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Home Office
Analytical Technology, Inc.
6 Iron Bridge Drive
Collegeville, PA 19426
Ph:(800) 959-0299
(610) 917-0991
Fax: (610) 917-0992
Email: sales@analyticaltechnology.com
Scan Alarm
USER
MANUAL
European Office
ATI (UK) Limited
Bank Chambers, 33 Stamford St.
Mossley, Ashton-u-Lyne OL50LL
Ph: 0800-018-4020
+ 44 (0) 1457 832800
Fax:+ 44 (0) 1457 839500
Email:sales@atiuk.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scan Alarm C14 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ATI Technologies Scan Alarm C14

  • Page 1 Scan Alarm USER MANUAL Home Office European Office Analytical Technology, Inc. ATI (UK) Limited 6 Iron Bridge Drive Bank Chambers, 33 Stamford St. Collegeville, PA 19426 Mossley, Ashton-u-Lyne OL50LL Ph:(800) 959-0299 Ph: 0800-018-4020 (610) 917-0991 + 44 (0) 1457 832800 Fax: (610) 917-0992 Fax:+ 44 (0) 1457 839500 Email: sales@analyticaltechnology.com...

  • Page 2: Product Warranty

    PRODUCT WARRANTY Analytical Technology, Inc. (Manufacturer) warrants to the Customer that if any part(s) of the Manufacturer's products proves to be defective in materials or workmanship within the earlier of 18 months of the date of shipment or 12 months of the date of start-up, such defective parts will be repaired or replaced free of charge.
  • Page 3 Safety Analytical Technology has made every effort to ensure the reliability and safety of the C14 Scanner and to recommended safe uses in systems applications. Note that in any application failures can occur. Good engineering practices, electrical codes, and insurance regulations require that you use independent external safety devices to prevent potentially dangerous or unsafe conditions.

  • Page 4: Features Include

    Introduction The C14 Scanner is a modular monitoring system with 16 fully independent inputs. It can function as a stand-alone system. The Scanner front panel has a Liquid Crystal Display (LCD) and touch keypad for local display and local parameter entry. You can also use it as the key element in a computer supervised data acquisition system;...
  • Page 5 Specifications This section contains specifications for inputs, outputs, serial interface, system power requirements, environmental specifications, and physical dimensions. Analog Inputs Number of Analog Inputs: 16 (4-20mA) single-ended / common ground. Other ranges are available on special order. Input Switching: Solid state multiplexer switching. Input Sampling Rate: 1.5x/second (667 ms) at 60 Hz;...
  • Page 6 Global Alarm Output Number: 1 Function: Monitors any combination of Alarms, Warnings, and Trouble. Digital Outputs – Zone Indicators Number: 12 Function: Monitors any combination of Alarms, Warnings, and Trouble. Table 1 ZONE DIGITAL OUTPUT Miscellaneous Specifications Serial Interface Type: RS-485 4 wire. Baud Rate: 2400 or 9600, user selectable.

  • Page 7: System Power Requirements

    System Power Requirements Voltage: 90-264 VAC universal, 47 to 63 Hz, 65 watts. Battery Backup: Optional 12VDC Environmental Specifications Storage Temperature: -20 to 60°C Operating Temperature: 0 to 40°C Humidity: 10 to 95% Non-Condensing. Physical Dimensions Scanner: Panel Mount 9.70”x4.00”x9.10”(246mm x 102mm x 230mm) Wall Mount 10.0”x21.3”x9.5”(254mm x 541mm x 241mm) - 7 -...

  • Page 8: Installation

    Installation This chapter describes how to install the Scanner. Installation of the Scanner involves the following procedures: • Determining the best location for the Scanner • Mounting the Scanner • Power Connection • Input Wiring • Communications Wiring (RS-485) • Output Wiring Safety DANGER...
  • Page 9 RS-485 Interface You can communicate with up to 32 Scanners on a single common loop. Wire equipment in a single “daisy chain” using twisted shielded pairs for the RS- 485 cables. Don’t use “octopus”, or “spurs”, or “star” patterns. Use the internal 200 Ohm terminating resistor on the RX line of the last Scanner in the system.

  • Page 10: Mechanical Installation

    Mechanical Installation Figure 1: Wall Mount Enclosure Dimensions (ATI-0247) - 10 -...
  • Page 11 Figure 2: Panel Mount Mounting Dimensions (ATI-0257) - 11 -...
  • Page 12 Figure 3: Panel Mount Enclosure Dimensions (ATI-0255) Figure 4: Panel Mount Version, Cutout Specs for Scanner, (ATI-0254) - 12 -...
  • Page 13 Figure 5: 2 Relay Module, Enclosure Dimensions (80-0040) - 13 -...
  • Page 14 Figure 6: 4 Relay Module, Enclosure Dimensions (80-0036) - 14 -...

  • Page 15: Electrical Connections

    Electrical Connections SEE APPENDIX 1 IN THE BACK OF THE MANUAL FOR THE GENERAL CONNECTION DIAGRAM - 15 -...
  • Page 16 Figure 7, A12 UniSens Connection (ATI-0256), CHANNEL 1 SHOWN - 16 -...
  • Page 17 Figure 8, B12 2 Wire Connections (ATI-0249) - 17 -...
  • Page 18 Figure 9, C12-17 Combustible Transmitter Connections (ATI-0251) - 18 -...
  • Page 19 Figure 10, Powered 4-20mA Input Transmitter Connections (ATI-0250) - 19 -...
  • Page 20 See Appendix 2 in back of manual for The Relay Module Wiring Diagram - 20 -...
  • Page 21 Using the C14 Scanner Introduction This chapter will show you how to operate the Scanner from the front panel. (If you are using ANASCAN, please see the ANASCAN User’s Guide.) The next diagram shows how to reach the operator menus from Single Channel Display. (To change global parameters, channel inputs, and alarms from the setup menus, you must enter a special sequence of keys.

  • Page 22: Front Panel

    Front Panel The front panel provides a convenient interface with the scanner system. You can program and operate the scanner with the front panel keys shown below, or you can use ANASCAN, a program designed specifically for the Scanner. Front Panel Keys Press Yes to: •...

  • Page 23: Alarm Reset

    WARNING A Manual System Reset clears the system’s memory and reinitializes the Scanner factory defaults. To do a Manual System Reset, power down the Scanner, press and hold the No key during power up. This is required during installation, after changing the EPROM, or when troubleshooting. If using ANASCAN you may need to set the communications baud rate, and protocol before communication can be established.

  • Page 24: Single Channel Display

    Single Channel Display Single channel Display (below) shows detailed information for one channel. From Single Channel Display, • Press to go to the next channel. • Press to go to the previous channel. • Press key once to go to job display (if it is enabled). •...

  • Page 25: Change Setpoint

    If you remotely loaded the job, Job display looks like this: If you modify a job’s parameters while job is running, you’ll see this message: If an alarm occurs, the controller switches to Single Channel Display. Change Setpoint To change the setpoint, go to the Single Channel Display of the channel you want to change, and press the key (the setpoint is the desired value for CHNG...

  • Page 26: Acknowledging An Alarm

    Alarms If alarm warning or trouble alarms occur, an eight character message is displayed in the lower-right section of the display. These messages are shown in the table below. Process Variable Engineering Units CHANNEL PROCESS UNITS ÿþ ÿ Channel Number Channel Name CHANNEL NAME ALARM STATUS...
  • Page 27 Setup Scanner Menus The Setup menus let you change detailed configuration information. How to Enter the Setup Menus 1. In Single Channel Display, select the channel you wish to edit. 2. While still in Single Channel Display, enter the pass sequence below: Press CHNG 3.
  • Page 28 See Appendix 3 in the back of the manual For the Scanner Software Flowchart Diagram - 28 -...
  • Page 29 Setup Global Parameters Menu The Setup Global Parameters menu looks like this. Load a Job Selectable values: 1 to 8 The following parameters are loaded as part of a job: • Setpoints and spread values. • Alarm functions (Off and Alarm), setpoints, high/low process setpoints, high/low deviation setpoints, and deadband settings, and channel alarm delay.
  • Page 30 Save Setup to Job Use this menu to save job information for every channel, to one of eight job in the Scanner battery-backed RAM. If a remote job has been selected by enabling remote jobs, the following message will appear on the display. Deselect the remote job if local job selection is desired.
  • Page 31 Below is the truth table that tells you which input states select which jobs. Digital Digital Digital Job # Input 3 Input 2 Input 1 Job Select Input Polarity This menu lets you set the polarity of the digital inputs used for job selection. You can set the active state to closed (low) or open (high).

  • Page 32: Scanner Address

    Keyboard Lock Status This selection lets you lock the front panel operator function key, CHNG ey, , so that pressing this key has no effect. If you want to use this function, turn off the Keyboard Lock. Selectable values: On or Off Scanner Address This menu allows you to set the Scanner address.

  • Page 33: Communications Protocol

    Communications Baud Rate This menu allows you to set the Communications Baud Rate. If using ANASCAN, ensure that the program has the same baud rate set through the ‘SCANINST’ program. Selectable values: 2400 or 9600 Communications Protocol This menu is located under the Setup Global Parameters main menu. It allows you to select the Communications Protocol.

  • Page 34: Digital Output Polarity

    Digital Output Polarity This menu lets you set the polarity of the digital outputs used for alarms. Selectable values: High or Low External Alarm Acknowledge Input An external alarm reset or acknowledge button can be wired to the Scanner. When activated, it performs the same function as if the key was pressed.

  • Page 35: Input Type

    The next section explains how to use the Input menus to configure your Scanner. Input Type This is the first menu of the Setup Channel Inputs menu, it lets you configure the input sensor for each channel as one of these input types. •...

  • Page 36: Channel Name

    Channel Name This menu lets you enter a channel name (up to seven characters) from this menu. If no name is entered, the Channel name will default to the current channel number. Input Units The Input Units menu lets you choose a three-character description of the channel’s engineering units.
  • Page 37 The example below shows a high PV of 10 PPM, and a low PV of 0 PPM. The high reading is the high end of the input signal (where 20 mA = 100%). Before you enter the values that determine the two points for the conversion line, you must choose an appropriate display format.

  • Page 38: Display Format

    Display Format This menu lets you select a display format for a linear input. Choose a format appropriate for your input range and accuracy. (You will only see the Display Format menu if you are editing a linear input.) The Scanner has several available display formats; the display format you choose determines the default values for the rest of the Linear Scaling Menus.
  • Page 39 Input Scaling High Reading CHANNEL PROCESS UNITS ÿþ þÿÿ CHANNEL NAME ALARM STATUS Use this menu to enter the input level that corresponds to the high process value you entered in the previous menu. For Linear Inputs, the high reading is a percentage of the full scale input range.

  • Page 40: Input Filter

    Input Filter The Scanner has two different types of input filters: • A noise rejection filter that rejects high frequency input signal noise. This filter keeps a “Trend Log” of input readings. If a reading is outside the filter’s “acceptance band”, and later readings are within the acceptance band, the Scanner ignores the anomalous reading.

  • Page 41: Process Alarms

    global alarm stays on until you use the front panel key (or ANASCAN) to acknowledge it. Process Alarms Process alarms include Alarm, Warning and Trouble alarms. You can set each of these alarms to Off, Latched or Unlatched. Function Description No Alarm Digital output activates on alarm.

  • Page 42: Alarm Delay

    Use menus to set the following process alarm parameters for each channel: • Alarm Warning and Trouble, setpoint, and digital output. • Alarm deadband • Alarm delay The setpoints, deviation alarm values, and deadband all use the same decimal format as the channel’s process variable. Alarm Delay You can set the Scanner to delay normal alarm detection and alarm reporting.

  • Page 43: Alarm Setpoint

    Alarm Setpoint This menu lets you select the setpoint (value within the scaled sensor range) at which the Alarm activates. The Alarm activates when the process variable (PV) goes above the Alarm setpoint. It deactivates when the PV goes below the Alarm setpoint minus the deadband value, if you have set a deadband value.
  • Page 44 Warning Value This menu lets you set the Warning band width, a positive and negative warning point relative to the setpoint. If the setpoint changes, the warning points also change. You can assign separate digital outputs to Hi and Lo Warnings. Selectable Values: 0 to 255, 35.5, 2.55, .255 or .0255, depending on the way you set up the Input menus.
  • Page 45 Warning Low This menu turns off Warning Low or sets it to the alarm function. Selectable Values: Off, Latched, Unlatched Warning Low Output Number This menu is used to assign a digital output that activates when the channel is in Warning Low Selectable Values: 1 to 34, None NOTE...

  • Page 46: Alarm Deadband

    Trouble Type This menu lets you turn off the Trouble Alarm, or set it to the Alarm Function. Selectable Values: Off, Latched, Unlatched Trouble Output Number This menu lets you assign the digital output that activates when the channel is in Trouble.
  • Page 47 Alarm Delay This menu sets a Channel Alarm Delay. There are two types of Alarm Delay: the Startup Alarm Delay, and Channel Alarm Delay. Startup Alarm Delay (which you can set in the Setup Global Parameters main menu), delays process alarms for all channels for a specified time after the Scanner powers up.

  • Page 48: Digital Output Selection

    Digital Output Selection This menu lets you select one of the Digital Alarm Outputs, to test in the next menu. Digital Output Test This menu lets you manually toggle a digital output On or Off to test it. (Select the output to test in the previous menu.) On may be Low or High depending on the digital output polarity you set.

  • Page 49: Annunciator Panel

    Annunciator Panel Global Alarm Illuminates to indicate that one or more inputs have an ALARM, WARNING or TROUBLE level. All occurrences must be acknowledged by pressing to extinguish the Global Alarm Lamp. System Fault Illuminates to indicate that the scanner has malfunctioned, and may need service.
  • Page 50 APPENDIX 1 – General Customer Connections Diagram (ATI-0248)
  • Page 51 Appendix 2 – Relay module wiring diagram (ATI-0271)
  • Page 52 APPENDIX 3 – Software Flowchart...
  • Page 53 APPENDIX 4 – Linear Scaling Example Situation A gas sensor that generates a 4-20 milliamp signal is connected to the scanner. The specifications of the sensor state that it generates 4 milliampsat 0.0 PSI and 20 mA at 50.0 PPM. Setup The Sensor measures PPM in tenths, so the appropriate display format is –999.9 to +3000.0.
