LED Sea-Vue® Light Instructions

12 & 24 Volt

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS: This manual contains important

safety and operating instructions for Sea-Vue Underwater LED

lights. CAREFULLY READ THESE INSTRUCTIONS BEFORE IN-

STALLING OR USING PRODUCT.

GENERAL PRECAUTIONS

Battery posts, terminals and related accessories contain lead and lead com-

ponents, and other chemicals known to the State of California to cause can-

cer and birth defects or other reproductive harm. Always wash your hands

after handling these devices.

Do not operate the Sea-Vue Lights with damaged power cables - Replace

damaged product immediately.

VOLTAGE COMPATIBILITY: NEVER use the Sea-Vue Lights power supply

(if used) unless the input voltage matches the Input voltage rating of the

power supply. For example, do not use a 12-volt power supply with a 24-

volt system.

MOUNTING LOCATIONS:

The Sea-Vue Lights LED lights must be

mounted at least 6" below the water line or on a dock as a dock light 6"

below the low tide waterline. If a power supply is used, it should be mounted

in a location with plenty of ventilation that is not likely to experience water

submersion.

Need help?

Do you have a question about the LED Sea-Vue and is the answer not in the manual?

Page 1 If a power supply is used, it should be mounted Hurley Marine, Inc. • 1125 Lake Shore Drive • Escanaba, MI 49829 USA in a location with plenty of ventilation that is not likely to experience water 906.
Page 2 LOCATION OF POWER CABLES: Make sure all electric power cables are tered, or utilized in a manner not approved by Hurley Marine, Inc. or subjected to normal wear and tear, abuse, located so that they cannot be stepped on, tripped over, chafed or otherwise misuse, improper maintenance, negligence or accident.
Page 3 Vessel Installation Instructions: SPECIFICATION SUMMARY: • Select a mounting location best suited to your particular needs. Technical Specifications (DC) • Surface Mounting: Mark the position. It is good practice to use tape on the sur- face to be drilled then drill the hole through the tape. This will avoid scratching/chip- DC Input Voltage 10.0 - 30 VDC ping of the surrounding surface.
Page 4 Additional Lights 5A FUSE • Mount power supplies & junctions inside a NEMA Type 6, IP67, or equivalent enclosure. For Hurley Marine switches, remotes, and relays, always • Use waterproof heat-shrink on all outdoor wire junctions. refer to their respective wiring instructions.
