Summary of Contents for Absolute Acoustics HDBASET NDS-570HD Series
- Page 1 NDS-570HD INSTALL GUIDE HDBASET™ EXTENDERS NDS-571HD-TX NDS-572HD-RX NDS-572HD-RX NDS-571HD-TX www.absoluteacoustics.com...
- Page 2 Some trademarks may be mentioned to refer to the entities that own such marks, names or their products. Absolute Acoustics® has no interest in the ownership of trademarks and trade names. Absolute Acoustics® is not responsible for errors in typography or photography and, in order to improve its products, reserves the right to change speci cations without notice.
-
Page 3: Key Features
NDS-570HD Introduction Absolute Acoustics® NDS-570HD is a Class B HDMI over HDBaseT™ extender set capable of transmitting HDMI and control signals for distances up to 230ft (70m) over a single twisted-pair cable. NDS-570HD is capable to extend 1080p video up to 230ft (70m) and 4K/UHD video up to 130ft (40m) with embedded multi-channel audio, RS232 and bi-directional IR control signals. - Page 4 NDS-570HD NDS-571HD-TX Description Link, HDCP and power status indicators HDMI input port RS232 extension port HDBaseT™ output port IR input/output extension ports DC power supply inlet NDS-572HD-RX Description Link, HDCP and power status indicators HDMI output port RS232 extension port HDBaseT™...
-
Page 5: Installation Instructions
NDS-570HD Installation Instructions QUICK SETUP GUIDE Begin with the NDS-570HD units and all external devices Warning turned o and with power cables removed. All devices should be unplugged from electrical supply prior to begin the Place the NDS-571HD-TX and NDS-572HD-RX units at the installation. -
Page 6: Rs232 Control
NDS-570HD Control Ports Configuration IR CONTROL IR Input ports of Absolute HDBaseT® transmitters can be used for signal extension, carrying the input signal to IR Output port on remote HDBaseT™ receiver unit. The connection cable between unit and the IR emitter equipment must be assembled with the following con guration: Signal Signal... - Page 7 NDS-570HD Specifications NDS-571HD-TX NDS-572HD-RX 10.2 Gbps SIGNAL BANDWIDTH HDMI COMPATIBILITY CEC, EDID, HDCP 2.2 800x600, 1024x768, 1280x768, 1280x960, 1280x1024, 1600x1200, SUPPORTED 1920x1080, 1920x1200, 3840x2160, 4096x2160 RESOLUTIONS 8 - 12 bits/ch COLOR DEPTH RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 COLOR FORMATS Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Digital, DTS-X, SUPPORTED AUDIO FORMATS...
-
Page 8: Package Contents
NDS-570HD Package Contents NDS-571HD-TX 1x NDS-571HD-TX 1x 24V DC @ 2A power supply 4x Regional adapter plugs 4x Rubber feet 1x Warranty certi cate NDS-572HD-RX 1x NDS-572HD-RX 4x Rubber feet 1x Warranty certi cate www.absoluteacoustics.com...
