Summary of Contents for Orcon HRC 300 4B P
Page 1
Heat recovery unit Type: HRC 300/400 4B(P/RH) This manual is intended for users and installers of type HRC 300/400 B(P/RH). This manual contains impor- tant about the operation and installation of the HRC 300/400 B(P/RH). Store near the appliance www.orcon.nl...
This is automatically Technical specifications detected and controlled by the unit electronics. Wiring diagram Orcon HRC 300/400 4B(P/RH) The electronics also ensures, that in winter, when ice-formation Appliance data HRC 300 4B(P/RH) in the exchanger is possible, the exchanger is defrosted, at a Fan graph HRC 300 4B(P/RH) time that is most comfortable to occupants of the dwelling.
2. Version 2.1 General The Orcon HRC is a complete heat recovery unit, which is fitted with an intelligent electronic control system to ensure optimum efficiency and protection under all conditions. The unit can easily be set up for left- or a right-handed opera- tion.
3. Installation switched spur) is also indicated. The unit must be secured horizontally. Ensure sufficient angle for the condensate discharge. The installation must be in a frost-free room. Make sure there is a free space of at least 80 cm at the front of the appliance for cleaning the filter and carrying out maintenance on the appliance.
= No exhaust too close to an air inlet The mechanical ventilation outlet, the air inlet and any soil & = Ventilation inlet possible near roof end vent pipes should each be separated by at least one meter. = Inlet roof terminal = Ventilated ridge tile = Outlet valve ø125 plastic (MKL) or metal (EFF-125) = Duct from and to outside - insulated...
3.5 Placing the heat recovery module 3.7.4 Speed control with a wireless remote control After fitting all the ducts at the mounting frame, and after fitting (BRH model only) the condensate discharge, the “heart” of the unit can now be The HRC 300/400 BRH is delivered prewired.
3.8 Overview connection HRC 3.9 Adjusting the air performance The HRC can be configured either as a standard or a mirrored The HRC is provided with constant volume fans. unit. As a standard unit, the duct connections on the left side The integrated electronics controls the speed of each ventilator, of the unit will go outside and the duct connections at the right to keep the airflow equal conform the settings of the dipswitches...
Page 8
Dipswitch settings HRC 300 4B(P/RH) Factory setting: 1 2 3 4 5 6 7 8 L = 100m M = 150m H = 225m Middle 1 = OFF, 2 = ON 3 = ON, 4 = OFF 90 m 125 m 1 = ON, 2 = ON 3 = OFF, 4 = ON 100 m...
Page 9
Dipswitch setting HRC 400 4B(P/RH) Factory setting: 1 2 3 4 5 6 7 8 L = 120m M = 180m H = 275m Middle 1 = OFF, 2 = ON 3 = ON, 4 = OFF 105 m 150 m 1 = ON, 2 = ON 3 = OFF, 4 = ON 120 m...
4. Maintenance 4.1 User maintenance User maintenance is limited to periodically cleaning the filters. The unit is fitted with a filter timer. If you have to clean the filters a red led in the panel will start flashing on/off. This filter indication will start flashing each month.
4.2 Installer maintenance Take out the heat exchanger (once every 3 years) • Switch off the power supply and remove the cover • Remove the bypass cover (1) • Clean the heat-exchanger with warm water and a mild • Remove the press tray (2) detergent.
Meaning LED-signs 4.3 Mounting of the heat-exchanger and the motor plates • Replace the heat exchanger and fans by reversing the instructions in 4.2 Normal function • Replace the heat exchanger from above and ensure that there is no leakage between supply and extract airflows. •...
5.2 Appliance data HRC 300 4B(P/RH) Fan settings Low speed Middle speed High speed Maximum speed Ventilation capacity, factory settings [m Rated power [W] 18-22 29-50 72-98 144-169 Rated current [A] 0.14-0.15 0.21-0.34 0.49-0.65 0.95-1.1 ϕ 0.60-0.61 0.62-0.63 0.64-0.65 0.66-0.67 Permissable duct/ system resistance [Pa] 160 Pa at 300 m Dimensions (w x h x d) [mm]...
5.3 Fan graph HRC 300 4B(P/RH) Power consumption per fan [w], see table Airflow (m Point [m3/h] [Pa] U [V] I [A] ϕ P [W] 0,068 0,602 0,070 0,604 0,075 0,612 10,6 0,102 0,626 14,8 0,110 0,621 15,7 0,120 0,625 17,3 0,188 0,643...
5.4 Appliance data HRC 400 4B(P/RH) Fan settings Low speed Middle speed High speed Maximum speed Ventilation capacity, factory settings [m Rated power [W] 18-22 29-50 72-98 173-350 Rated current [A] 0.14-0.15 0.21-0.34 0.49-0.65 1.8-2.27 ϕ 0.60-0.61 0.62-0.63 0.64-0.65 0.66-0.67 Permissable duct/ system resistance [Pa] 150 Pa at 400 m Dimensions (w x h x d) [mm]...
5.5 Fan graph HRC 400 4B(P/RH) Power consumption per fan [w], see table Airflow (m Point [Pa] U [V] I [A] ϕ P [W] 0.080 0.509 0.083 0.511 0.088 0.519 0.120 0.533 0.129 0.528 0.141 0.532 0.220 0.550 0.223 0.549 0.262 0.559 0.334...
5.6 Setting transmitter / receiver (RH model only) Battery replacement. When current is put on the device, the red LED is flashing 3x on When the LED indication on the remote does not react when one the receiver print. of the buttons on the remote is pushed, it is probably due to a low battery.
Appliance type : HRC 400-4BP The R&TTE directives 1999/5/EEG and the EMC-directives Serial number : 091180031 2004/100 EEG. Orcon bv warrants that the heat recovery Year of production : 2009 appliances are manufactured from high-quality materials Part : Motor HRC 400...
Page 20
Orcon bv Storkstraat 23, 3905 KX Veenendaal (NL) P.o. box 416, 3900 AK Veenendaal t +31 (0)318 54 47 00 f +31 (0)318 54 47 06 info@orcon.nl www.orcon.nl...
