Summary of Contents for AITZ ALPHA

Page 2: Table Of Contents
8. Installation …………………………………………… 11 9. F u n c t i o n s … … … … … … … … … … … … … … … 1 3 10. AITZ ALHPA GUI ……………………………………… 16 11. PC viewer ……………………………………………...
Page 3: Introduction
Forward Collision Warning System(FCWS) and STOP&GO. Also record the front/rear image with sound. • AITZ ALPHA can save the driving/accident image and sounds together, also check the video image by 3.5 inch full touch screen.  AITZ is a trademark belonging to ATM CO., LTD.
Page 4: Cautions Before Using
Cautions before using • Warranty and Limited Liability  AITZ ALPHA is a supplementary device for your safe driving. The manufacturer shall not be liable for any loss or damage caused by product failure, data loss or use of the product.
Page 5: Cautions When Using
 Please install the product a windscreen avoid deep tinted windows or metal coating. GPS receiving error will be happen, and recording resolution will be indistinct.  Do not operating or states during driving. It could be cause of accident. Please use device after safety parking. AITZ ALPHA User Manual...
Page 6  When the Micro SD Card is full, the oldest file in the card will be overwritten by a new file. Please back up data periodically to prevent unwanted data loss.  Please watch out for using Micro SD card and removing it. Please remove the power cable before inserting or removing the Micro SD Card. AITZ ALPHA User Manual...
Page 7: Features
• Super Cap : Record the normally when shut-down the device • ADAS : LDWS(Lane departure warning system), Forward Collision Warning System(FCWS),STOP&GO • Save the speed/location by GPS • Voice guidance • Cut-off voltage • High-quality MIC • Exclusive PC viewer AITZ ALPHA User Manual...
Page 8: Components
Components Option Components Main power cable TAPE Sheet GPS module Bracket Bracket TAPE AITZ ALPHA device Quick guide Rear camera Micro SD Card AITZ ALPHA User Manual...
Page 9: Part Names
③ Enforced recording button ④ Power button ⑤ Volume ⑥ Operated LED ⑦ Micro SD card Slot ⑧ GPS port ⑨ Reset button ⑩ Rear camera port ⑪ I/F port ⑫ Power port ⑬ Security LED ⑭ Bracket AITZ ALPHA User Manual...
Page 10 Button, LED operation • LED indication Status YELLOW BLUE Power Booting Recording start Pause (Repeat) Parking mode (Repeat) Motion detection (Repeat) Event recording Driving / User recording Power off (Follow the step) AITZ ALPHA User Manual...
Page 11: Installation
• Please not that heavy glass tint or thermal wire in the glass may impair the recording quality. • After install the product, please remove the camera’s protective plastic. • Please avoid deep tinted glass or metallic coating on windshield when installation. It may cause of GPS receiving error. AITZ ALPHA User Manual...
Page 12 3. Connect to the cables by Rear camera > I/F > Power steps. 4. When connect to the power cable, booting is start with AITZ logo. 5. When booting is completed, the front video will be displayed with voice guidance “Recording is start.”.
Page 13: F U N C T I O N
 Working speed can set the [ADAS] > [Speed].  ADAS system may be not working on decipher faded, missing, or incorrect lane markings. Markings covered in snow or old lane markings left visible can hinder the ability of the system. AITZ ALPHA User Manual...
Page 14 ② Set the red line to the horizon using Volume button and push the Enforced recording button(●). ③ Set the red line on bonnet of car using volume button. ④ Set the red line on right line of car using Volume button. AITZ ALPHA User Manual...
Page 15: Aitz Alhpa Gui
AITZ ALPHA GUI • GUI Main screen Recording mode Rear cam Front Cam Input voltage Temperature Date / Time (This sign can show when GPS in connected.) AITZ ALPHA User Manual...
Page 16 AITZ ALPHA GUI • Menu ① ② ① Back ② Main screen ③ Voice recording ⑤ ④ Play video ④ ③ ⑤ Format ⑥ ADAS ⑦ Recording setting ⑥ ⑦ ⑧ ⑧ System setting AITZ ALPHA User Manual...
Page 17 AITZ ALPHA GUI • Play video ① Select the recording mode which user play file. ② Select the video file AITZ ALPHA User Manual...
Page 18 AITZ ALPHA GUI • Format ① “Yes” – SD Card format start “No” – Back to the previous screen AITZ ALPHA User Manual...
Page 19 ② FCWS: ON/OFF ③ STOP&GO: ON/OFF ④ ADAS Voice guidance : ON/OFF ⑤ Limit speed setting - 60,80,100 km ⑥ ADAS Calibration setting • Recording setting ① Sensitivity ② Voice setting ③ Cut-off voltage ④ Memory control AITZ ALPHA User Manual...
Page 20 ① Motion - Low, Middle, High ② Event - Low, Middle, High ③ Parking event - Low, Middle, High • Voice guidance ① MIC Volume – 1(Low), 2(Middle), 3(High) ② Voice guidance: ON/OFF ③ Voice recording : ON/OFF AITZ ALPHA User Manual...
Page 21 - No use, 6 hours, 12 hours, 18 hours, 24 hours, 48 hours Memory management • ① Memory management - Set the quota by 10% from 30% to 70% - Drive mode : Drive 70%, Event 30% - Parking mode : Motion 50%, Event 50% AITZ ALPHA User Manual...
Page 22 ④ System status ⑤ System reset Time setting • ① Time setting GMT standard time set using “<“, ”>” button. Year, Month, Day, Hours, Minutes GMT +8 2015 ※ If GPS connect, this will base on GPS time. AITZ ALPHA User Manual...
Page 23 AITZ ALPHA GUI • Screen setting ① “LCD ON” - Display the main screen ② “Auto off” - Screen saver displays on LCD ③ “Clock” - Display the time on LCD ④ “LCD OFF” - LCD OFF AITZ ALPHA User Manual...
Page 24 AITZ ALPHA GUI • Coordinated correction ① Touch the center point of “+” . - Upper-left, Middle center, lower-center AITZ ALPHA User Manual...
Page 25 AITZ ALPHA GUI • System reset ① “Yes” – All setting is reset “No” - Back to preview AITZ ALPHA User Manual...
Page 26 AITZ ALPHA GUI • System status ① Display the device version and information. AITZ ALPHA User Manual...
Page 27 PC Viewer Installation • PC viewer can download on http://www.aitz.co.kr > Download > S/W download the‘ AITZ Alpha viewer’. Then exact the installed file. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ AITZ ALPHA User Manual...
Page 28: Pc Viewer
Play to original size Hide/End File name Play list Play screen Play Rear / Map interlock Impact detection Drive speed Switch to map Setting Viewer info. Bright/Volume Screen capture Switch to Front/Rear Save to the another file Play speed AITZ ALPHA User Manual...
Page 29 • Display construction Load file Play / Pause Playback previous file Move to previous file Play Bright of play control Play speed bar control Temporary stop Move to next frame Volume control Playback to next file AITZ ALPHA User Manual...
Page 30 • Display size  When play the recording file, the files play on Viewer size.  If user want to play original size, can click on “Play to original size”.  The original size is 1280X720. AITZ ALPHA User Manual...
Page 31  When click on “Image capture” button, there is a window for save the image.  Write the file name and choose the location on the file and click the“save”button, then the capture files is saved on the location. AITZ ALPHA User Manual...
Page 32  When click the “Save video file” button, there is a window for save the video.  Write the name of video file(Basic: original video file) and select the location then video image will save in the location. AITZ ALPHA User Manual...
Page 33 PC Viewer • Switch to Front/Rear screen AITZ ALPHA User Manual...
Page 34 PC Viewer • Switch to the map AITZ ALPHA User Manual...
Page 35 PC Viewer • Setting AITZ ALPHA User Manual...
Page 36: Setting
 Off : LCD off  Time : Clock  Change the time : Set the screen saver time  1min : Change to 1min  3mins : Change to 3min  5mins : Change to 5min AITZ ALPHA User Manual...
Page 37  80 Km : Over 80 Km • System  Cut-off voltage : Set the cut-off voltage 12.5 23.8 25.0 11.5 0.2V 0.2V  Time setting : set the blackbox time  When apply the GPS module, satellite time will display. AITZ ALPHA User Manual...
Page 38: Specifications
Voice Voice guidance Apply guidance Input port 2 포트 1port - External camera , 1port- I/F Operated indication LED (Red, Blue, Yellow) Embedded Others Power cable Include Power DC 10V~24V Operated temperature -10℃ ∼ 70℃ AITZ ALPHA User Manual...
Page 39 • Thank you for purchasing AITZ blackbox. • If you have any problems or inconvenience of product, please contact us. • Customer support center  Contact: +82-1670-8727  Working hours: 10 : 00 ~ 18 : 00  Address: 92, Hamwol 20-gil, Seongan-dong, Jung-gu, Ulsan, Korea 44416 ...
