VST FUEL S-810
INSTALLATION INSTRUCTIONS
VST 002.001
# 09805988
Revised 6/10
This document contains information proprietary to VST Fuel Management, Inc. and shall not be disclosed,
duplicated, or used for procurement, design, or manufacture, without the expressed written consent of VST Fuel
Management, Inc..
Copyright 2008 by VST Fuel Management, Inc.
All rights reserved
​ VST, 2010
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-810 and is the answer not in the manual?

Questions and answers

Summary of Contents for VST S-810

  • Page 1 Revised 6/10 This document contains information proprietary to VST Fuel Management, Inc. and shall not be disclosed, duplicated, or used for procurement, design, or manufacture, without the expressed written consent of VST Fuel Management, Inc.. Copyright 2008 by VST Fuel Management, Inc.
  • Page 2 THE SYSTEM VALIDITY CODE. READ THIS IMPORTANT SAFETY INFORMATION BEFORE INSTALLING THE VST FUEL MANAGEMENT S-810 SYSTEM. Parts of this product are installed and operated in the environment surrounding a gasoline service station. It is important that you, the installer, take every precaution to prevent possible hazards which could result in serious bodily injury and property damage.

  • Page 3: Table Of Contents

    4.2 Wire Manufacturers 4.3 Dispensers/Pumps Table 1. Size of Dispenser Junction Box b. Interface wiring c. Dispenser wiring Figure 4. Typical Wiring for 115Vac or 230 Vac VST Fuel S-810 Wiring Diagram 4.4 Communications 5. VST FUEL S-810 WIRING VERIFICATION 5.1 General 5.2 Diagnostics check...

  • Page 4: Introduction

    1.1 General    This instruction manual is intended to assist the user with the installation of the VST Fuel S-810 Fuel Management System. Due to wide variations in dispenser/pump wiring and fueling site layout, it is virtually impossible to provide detailed instructions for each individual installation. This manual provides a general description of various types of installations applicable to VST Fuel S-810 systems.
  • Page 5     Figure 1. Typical Installation of VST Fuel S-810 ​ VST, 2010...

  • Page 6: Product Description

    RS-232 or RS-485 compatible. The various system operations for control of the VST Fuel S-810 and the generation of reports from the VST Fuel S-810 are thru priority VST Fuel Management, Inc. software. These commands may be issued locally from a personal computer or remotely by dial-up communications from a personal computer, , or other serial communication device.

  • Page 7: Getting Started

    4. A Junction box of sufficient volume for each dispenser. 2.3 Return Shipping  All return shipments of VST products must be prepaid. Return items in their original shipping containers. VST will accept no liability for damage caused by improper packing. Address the shipment to: Service Department VST Fuel Management, Inc.
  • Page 8 The VST Fuel S-810 (DET) may be mounted using either of two methods. The first method is mounting the DET on the top of a 2 inch pipe x 55” (approx.) height. The DET is simply screwed onto the pipe and after being positioned for operation the two set screws in the mounting hub are tightened to prevent the DET from turning during normal operation.

  • Page 9: Figure 2. Vst Fuel S-810 Dimensions

    Figure 2. VST Fuel S-810 Dimensions       ​ VST, 2010...

  • Page 10: Figure 3. Vst Fuel S-810 Pedestal Mounting

    Figure 3. VST Fuel S-810 Pedestal Mounting ​ VST, 2010...

  • Page 11: Conduit Installation

    3.2 Conduit installation  Conduit must be installed for the VST Fuel S-810 wiring. Refer to the National Electric Code and applicable local codes for specific requirements. Generally, rigid metallic conduit is recommended for all wiring due to its electrical noise shielding and durability characteristics. Other types of conduit may be used as allowed by the National Electric Code and applicable local codes if proper precautions are taken in its application.

  • Page 12: Table 1. Size Of Dispenser Junction Box

    This equipment is intended for self-service type dispensing devices containing equipment suitable for that purpose. The wiring diagrams contained here typify installation circuits for dispensers containing: Computer electric reset actuator (when provided) Pulse transmitter with appropriate ratings ​ VST, 2010...

  • Page 13: Interface Wiring

    1. Typical dispenser-to-VST Fuel S-810 field wiring diagrams are included in this section (see drawing). The VST Fuel S-810 connections are shown in the drawing as they appear on the back of the VST Fuel S-810 with the cover removed. (Installations may vary from this concept due to wiring codes and other circumstances.) Wiring diagrams of dispensers are used as examples only and in no way imply that the units used with the system must be rewired to conform with the drawings.
  • Page 14 This switch normally is part of the electric reset. If the proper switch is not available, a relay may be used. The switch or relay contact allows the pulser to count into the VST Fuel S-810 input only after the dispenser computer has been reset to zero.

  • Page 15: Communications

    5.1 General  In order to verify the wiring it is convenient to have the VST Fuel S-810 operational (ac power applied) and be familiar with some of the basic built-in diagnostic tools. This section is a brief explanation of the built-in diagnostics.

  • Page 16: Diagnostics Check

    You can now perform the diagnostic tests from the keypad on the front panel of the VST Fuel S-810. Each of the following diagnostic tests are engaged by keying in the number of the desired diagnostic routine. To go to the next diagnostic routine or to terminate the current one, press CLEAR ENTRY.

  • Page 17: Dispensers/Pump Control

      Turn the On/Off switch inside the VST Fuel S-810 to the Off position. Turn on the breaker and measure the ac voltage at the terminals labeled "L" and "N" on the back of the VST-Fuel 810 (TB-1). The measured voltage should be approximately 115 Vac.

  • Page 18: Handle Switch/Run Circuit

    After the first ninety (90) days of the warranty period, VST will repair or replace the product only if it is returned to the VST factory (at the Tempe facility), transportation prepaid.

  • Page 19: Limitation Of Damages

    6.3 Inspection and Limitation of Actions  The user must inspect the product promptly after receipt and notify VST Fuel Management, Inc., in writing, of any claims, including claims of breach of warranty, within thirty days after the facts upon which the claim is based are discovered or should have been discovered.
